| Ref | Part Number | Description |
|---|
| 0 |
640330 |
CARBURETOR Price: $75.33 |
| 1 |
532124657 |
EXT SPRING Price: $8.99 |
| 1 |
640035 |
SHAFT & LEV Price: $7.17 |
| 1A |
36288 |
BUSHING Price: $1.22 |
| 2 |
640036 |
SPRING Price: $1.20 |
| 2 |
873640400 |
Nut, Hex, Keps 1/4-20 Price: $2.99 |
| 3 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 4 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 5 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 5 |
640037 |
WASHER Price: $1.20 |
| 6 |
532122549 |
BRKT HOOD RH Price: $2.45 |
| 6 |
640332 |
SHUTTER Price: $3.22 |
| 7 |
532122548 |
BRKT HOOD LH Price: $2.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
817521312 |
Screw Sltd. Hex Hd W/PL Washer Price: $1.05 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 10 |
532123693 |
BRACE,HOOD Price: $5.99 |
| 10 |
640044 |
SHAFT & LEV Price: $1.55 |
| 11 |
532132918 |
HOOD This part replaces 532140463. Price: $257.40 |
| 11 |
632785 |
SPRING Price: $1.20 |
| 12 |
532122035 |
LENS Price: $14.99 |
| 13 |
532142325 |
GRILL YP W/HL Price: $36.35 |
| 14 |
640913 |
SHUTTER Price: $1.30 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 25 |
640331 |
FLOAT BOWL Price: $15.22 |
| 25A |
640334 |
BOWL KIT Price: $20.46 |
| 27 |
632544A |
FLOAT SHAFT This part replaces 632544. Price: $2.61 |
| 28 |
632543 |
FLOAT Price: $6.73 |
| 29 |
640047 |
GASKET Price: $2.60 |
| 30 |
632709 |
INLET NEEDLE Price: $4.91 |
| 32 |
640041 |
SCREW Price: $1.25 |
| 33 |
27110A |
GASKET Price: $1.45 |
| 36 |
640067 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 38 |
632545 |
SPRING Price: $0.87 |
| 38A |
36918 |
SPRING Price: $1.18 |
| 39 |
640218A |
RETAINER Price: $2.28 |
| 40 |
632788 |
FUEL JET Price: $1.99 |
