| Ref | Part Number | Description |
|---|
| 1 |
277069 |
Gasket Price: Call Us |
| 2 |
52_053_66 |
Carburetor Price: Call Us |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
25_155_02 |
Connector-90? Price: Call Us |
| 4 |
25_158_09 |
Bushing Price: Call Us |
| 5 |
5218606 |
Arm-Governor Price: Call Us |
| 6 |
82_755_07 |
Kit-Governor Linkage (Incl. Ref. #13) Price: Call Us |
| 7 |
52_041_09 |
Gasket-Intake Price: Call Us |
| 8 |
52_164_10 |
Manifold-Intake Price: Call Us |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
X-21-1 |
Washer Price: Call Us |
| 10 |
X-6-8 |
Screw-H.C. Price: Call Us |
| 11 |
X-352-37 |
Stud Price: Call Us |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 12 |
X-77-2 |
Nut Price: Call Us |
| 13 |
52_445_02 |
Strap-Lifting Price: Call Us |
| 14 |
25_086_27 |
Screw-Throttle Plate Price: Call Us |
| 15 |
25_146_03 |
Plate-Choke Price: Call Us |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438080. Price: $199.99 |
| 16 |
25_194_01 |
Ball-Choke Price: Call Us |
| 17 |
25_089_03 |
Spring-Choke Price: Call Us |
| 18 |
52_144_18 |
Shaft-Throttle Lever Sea Price: Call Us |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
25_146_02 |
Plate-Throttle Price: Call Us |
| 20 |
25_368_01 |
Valve-Needle Price: Call Us |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
25_089_02 |
Spring Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
25_368_03 |
Needle-Main Fuel Price: Call Us |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
25_086_26 |
Screw Price: Call Us |
| 24 |
25_089_04 |
Spring Price: Call Us |
| 25 |
25_089_02 |
Spring Price: Call Us |
| 26 |
52_090_12 |
Lever-Choke Price: Call Us |
| 27 |
25_041_04 |
Bowl-Gasket Price: Call Us |
| 28 |
25_757_09 |
Kit-Float Price: Call Us |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
25_104_01 |
Bowl Price: Call Us |
| 30 |
25_041_03 |
Gasket-Bowl Price: Call Us |
| 31 |
25_100_05 |
Screw-Bowl Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
