| Ref | Part Number | Description |
|---|
| 1 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 2 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 3 |
322-3 |
SCREW-HH Price: $0.79 |
| 4 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 5 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
105-0102 |
CABLE-THROTTLE Price: $55.32 |
| 7 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 8 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 9 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 10 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 11 |
70-1480 |
RELAY Price: $105.19 |
| 12 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
321-14 |
SCREW-HH Price: $0.55 |
| 15 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 16 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 17 |
93-7598 |
LEVER-THROTTLE This part replaces 93-7598-03. Price: $39.13 |
| 18 |
233-42 |
KNOB Price: $12.88 |
| 19 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 20 |
105-7528 |
DECAL-INFORMATION, SOLENOID Price: $40.89 |
| 21 |
105-3352 |
HARNESS-WIRE, MAIN Price: $768.43 |
| 22 |
106-7789-03 |
BRACKET-CONTROLLER Price: $24.71 |
| 23 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 24 |
52-5910 |
RING-RETAINING Price: $3.64 |
| 25 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 26 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 27 |
32128-25 |
NUT-HF Price: $3.19 |
| 28 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 29 |
105-4674 |
DECAL-NOISE Price: $4.80 |
| 30 |
85-6910 |
DECAL-RATING, NOISE Price: $7.03 |
| 31 |
2412-150 |
CLIP-J Price: $1.63 |
| 32 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 33 |
94-8146 |
STRIP-FOAM Price: $8.78 |
| 34 |
66-8800 |
RELAY Price: $87.56 |
| 35 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
