| Ref | Part Number | Description |
|---|
| 1 |
21-2660-01 |
PLATE-SIDE This part replaces 21-2660. Price: $299.86 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144926. Price: $139.99 |
| 2 |
66-6390 |
DECAL-CAUTION This part replaces 21-3920. Price: $27.63 |
| 2 |
874760412 |
Bolt, Hex Head 1/4-20 x 3/4 (AYP part number) Price: $3.99 |
| 3 |
22-7830 |
DISCONTINUED Price: Call Us |
| 3 |
819091016 |
Washer 9/32 x 5/8 x 16 Gauge (AYP part number) Price: $2.99 |
| 4 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 4 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 5 |
22-7810 |
SPACER Price: $16.90 |
| 6 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 7 |
28-1590 |
THROTTLE CONTROL This part replaces 21-2200. Price: $35.36 |
| 7 |
532007697 |
Tube, Tray, Battery (AYP part number) Price: $6.23 |
| 8 |
21-9970 |
DISCONTINUED X-REF Price: Call Us |
| 8 |
532007603 |
TRAY.BATTERY This part replaces 532124886. Price: $3.99 |
| 9 |
28-1600 |
CHOKE CONTROL This part replaces 21-2210. Price: $42.26 |
| 9 |
532109596 |
Clamp, Hose (AYP part number) Price: $2.99 |
| 10 |
233-35 |
KNOB Price: $8.06 |
| 10 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145211. Price: $7.99 |
| 11 |
3290-134 |
SCREW Price: $0.27 |
| 11 |
532150109 |
BATTERY HOLDDOWN This part replaces 532145209. Price: $4.99 |
| 12 |
38-4550-03 |
COVER-INSTRUMENTS This part replaces 23-2040. Price: $448.71 |
| 12 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145769. Price: $7.99 |
| 13 |
27-7290 |
DECAL-PTO This part replaces 21-3950. Price: $17.38 |
| 14 |
12-8140 |
KEY SWITCH Price: $39.86 |
| 15 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 16 |
83-0820 |
GAUGE - AMMETER This part replaces 18-2190. Price: $76.09 |
| 17 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 18 |
21-2510 |
DISCONTINUED Price: Call Us |
| 19 |
3290-360 |
SCREW-HH Price: $4.34 |
| 19 |
810040400 |
LOCKWASHER This part replaces 810090400. Price: $3.99 |
| 20 |
322-3 |
SCREW-HH Price: $0.79 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $3.99 |
| 21 |
21-2370 |
DISCONTINUED Price: Call Us |
| 21 |
532136850 |
Harness, Socket, Light (w/4152J) (AYP part number) Price: $15.99 |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
532004152 |
Bulb, Light (AYP part number) Price: $2.99 |
| 23 |
106-5190 |
BATTERY This part replaces 13-6480. Price: $170.85 |
| 24 |
32103-2 |
NUT-WING Price: $0.68 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $6.99 |
| 25 |
24-6420-03 |
HOLDDOWN-BATTERY This part replaces 21-2840. Price: $55.90 |
| 25 |
532146148 |
Cable, Battery 6 Ga. 22" Red w/16 Wire (AYP part number) Price: $11.99 |
| 26 |
3217-7 |
NUT-HEX Price: $0.28 |
| 26 |
532108824 |
Fuse (AYP part number) Price: $3.99 |
| 27 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 28 |
2412-41 |
CLAMP-R Price: $4.82 |
| 28 |
532145491 |
Cable, Ground 21" Blk 6 Ga. 90T (AYP part number) Price: $6.99 |
| 29 |
323-6 |
SCREW-HH Price: $0.66 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 30 |
21-5510 |
DISCONTINUED Price: Call Us |
| 30 |
532144921 |
Switch, Ignition (AYP part number) Price: $11.99 |
| 31 |
18-7040 |
DISCONTINUED Price: Call Us |
| 31 |
532145774 |
KIT-WASHER/NUT This part replaces 532140400. Price: $3.99 |
| 32 |
3229-10 |
SCREW-CARR Price: $0.22 |
| 32 |
532141226 |
Bezel, Ignition (AYP part number) Price: $3.99 |
| 33 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 33 |
532140401 |
Key, Molded (AYP part number) Price: $3.99 |
| 34 |
3217-5 |
NUT-HEX Price: $0.25 |
| 34 |
532110712 |
Switch, Light (AYP part number) Price: $4.99 |
| 35 |
23-1310 |
DISCONTINUED Price: Call Us |
| 35 |
532108236 |
Bracket Switch Interlock (AYP part number) Price: $2.99 |
| 36 |
817021008 |
Screw, Hex Tap #10-24 UNC (AYP part number) Price: $1.99 |
| 36 |
93-3183 |
TOOL BOX ASM This part replaces 23-2060. Price: $240.67 |
| 37 |
3217-6 |
NUT-HEX Price: $1.19 |
| 38 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 39 |
21-2770 |
PAD-FLOOR PLATE, RH Price: $96.81 |
| 39 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $4.99 |
| 40 |
21-2760 |
PAD-PLATE FLOOR, LH Price: $96.42 |
| 40 |
532145493 |
Harness, Ignition (AYP part number) Price: $90.71 |
| 41 |
871110412 |
Bolt, Hex 1/4-20 x 3/4 (AYP part number) Price: $3.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $14.99 |
| 44 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 45 |
532122822 |
Ammeter Rectangular (AYP part number) Price: $11.99 |
| 46 |
532141940 |
Protection Wire Loop Price: $3.99 |
| 49 |
811151000 |
Washer, Lock Internal Tooth 5/8 (AYP part number) Price: Call Us |
| 50 |
532154959 |
SWITCH PTO 3 PDT This part replaces 532140404. Price: $39.99 |
| 51 |
532140405 |
Ring, Retainer PTO (AYP part number) Price: $3.99 |
| 55 |
817490508 |
Screw, Thdrol. 5/16-18 x 1/2 Tyt (AYP part number) Price: $3.99 |
