| Ref | Part Number | Description |
|---|
| 1 |
138-6909 |
ENGINE-KUBOTA, D1105 Price: $8,188.27 |
| 2 |
43-0090 |
SCREW-HH Price: $8.05 |
| 3 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 5 |
323-14 |
SCREW-HH Price: $1.34 |
| 6 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 8 |
138-6462 |
SUPPORT-ISOLATOR Price: $4.17 |
| 9 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 10 |
115-8066-0P |
MOUNT-ENGINE Price: $42.18 |
| 11 |
115-8063-0P |
MOUNT-ENGINE RH Price: $26.00 |
| 12 |
99-8343 |
GASKET-MUFFLER Price: $14.99 |
| 14 |
104-2612 |
NUT-HF Price: $0.70 |
| 15 |
147-6082-0P |
BRACKET-TAILPIPE Price: $17.59 |
| 16 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 17 |
106-5277 |
AIR CLEANER ASM Price: $134.07 |
| 18 |
127-2696 |
HOSE-FORMED Price: $98.73 |
| 19 |
117-5164 |
HOSE-FORMED Price: $61.38 |
| 20 |
127-2695-0P |
BRACKET-AIR CLEANER Price: $29.14 |
| 21 |
121-5610-0P |
STAND W.A. AIR CLEANER (WELDED) Price: $170.02 |
| 22 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 23 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 24 |
127-2550 |
BRACKET-MUFFLER Price: $371.44 |
| 25 |
127-2698 |
HEADER-EXHAUST Price: $77.34 |
| 26 |
127-2503 |
MUFFLER-EXHAUST Price: $629.70 |
| 27 |
2112-9 |
CLAMP Price: $7.78 |
| 28 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 30 |
100-4825 |
BAND-MOUNTING, AIR CLEANER Price: $80.59 |
| 31 |
322-10 |
SCREW-HH Price: $0.70 |
| 33 |
127-2612 |
GUARD-PIPE, TAIL Price: $11.72 |
| 34 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 35 |
119-4478 |
SENDER-TEMPERATURE Price: $80.84 |
| 36 |
105-2409 |
SCREW-HSH Price: $0.68 |
| 37 |
125-1562 |
ACTUATOR-FUEL Price: $953.49 |
| 38 |
115-8068-0P |
MOUNT-ENGINE, LH Price: $27.05 |
| 39 |
107-1045 |
SPRING-EXTENSION Price: $4.89 |
| 40 |
125-1472-0P |
BRACKET-SPRING, THROTTLE Price: $12.42 |
| 41 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 42 |
33114-016 |
SCREW-HH Price: $0.27 |
| 43 |
127-2507 |
GASKET-ACTUATOR, FUEL Price: $11.17 |
| 44 |
114-4681 |
SCREW-HHF Price: $0.89 |
| 45 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
