| Ref | Part Number | Description |
|---|
| 1 |
127-3104 |
INJECTOR ASM Price: $2,681.46 |
| 2 |
127-3118 |
RAIL ASM Price: $3,160.31 |
| 3 |
125-7215 |
BOLT Price: $3.48 |
| 3 |
532143995 |
PULLEY, TRANSAXLE Price: $27.99 |
| 4 |
127-2982 |
RETAINER Price: $22.39 |
| 6 |
127-3082 |
RAIL IN PIPE ASM Price: $66.55 |
| 8 |
127-3121 |
INJECTION PIPE ASM Price: $102.18 |
| 8 |
532165619 |
ROD.SHIFT.FENDER.ADJ.LT.CRD Price: $19.99 |
| 9 |
127-3083 |
INJECTION PIPE ASM Price: $91.51 |
| 9 |
532169992 |
CLUTCH Price: $399.99 |
| 10 |
127-3122 |
INJECTION PIPE ASM Price: $102.18 |
| 11 |
127-3084 |
INJECTION PIPE ASM Price: $91.51 |
| 12 |
125-7231 |
NUT Price: $3.77 |
| 20 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532150280. Price: $2.99 |
| 21 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $8.99 |
| 23 |
532170171 |
BRACKET.ASM.CLUTCH Price: $22.99 |
| 29 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 30 |
532130807 |
BRACKET TRANSAXLE Price: $3.99 |
| 34 |
532165496 |
SHAFT Price: $30.99 |
| 35 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 37 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532124963. Price: $3.99 |
| 38 |
532165936 |
PULLEY.FLAT Price: $22.99 |
| 40 |
532124965 |
SPACER T Price: $3.99 |
| 47 |
532139245 |
PULLEY IDLER This part replaces 532127783. Price: $32.99 |
| 48 |
532154407 |
BELLCRANK, CLUTCH Price: $5.99 |
| 49 |
531151801 |
SERVICE KIT RETAIN BELT RETAIN This part replaces 532123205. Price: $3.99 |
| 52 |
596040501 |
Hardware This part replaces 532171026. Price: $2.99 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 55 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 57 |
532165632 |
V-BELT.0650.CRD.TRACTOR Price: $64.99 |
| 62 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 63 |
532145868 |
PULLEY, CLUTCH ELECT EVX Price: $69.99 |
| 66 |
531151001 |
SERVICE KIT BELT KEEPER This part replaces 532154778. Price: $6.99 |
| 71 |
532140158 |
STRAP LH TORQUE Price: $5.99 |
| 73 |
532156347 |
STRAP TORQUE RH HYDRO Price: $4.99 |
| 74 |
532121199 |
SPACER SPLIT Price: $3.12 |
| 75 |
532121749 |
WASHER This part replaces 532171038. Price: $2.99 |
| 76 |
812000001 |
E-RING LT Price: $3.99 |
| 77 |
532123583 |
SQUARE KEY Price: $3.99 |
| 78 |
532121748 |
WASHER This part replaces 532171039. Price: $3.99 |
| 81 |
532165585 |
SHAFT Price: $27.99 |
| 82 |
532123782 |
SPRING,TORSION Price: $3.99 |
| 84 |
532165629 |
LINK TRANSAXLE Price: $4.99 |
| 94 |
532140462 |
FAN 7" HYDRO Price: $9.99 |
| 104 |
532140156 |
CONTROL ARM Price: $4.99 |
| 150 |
532165850 |
BUSHING.BELLCRANK.GRD.DR Price: $4.99 |
| 156 |
596218801 |
Washers This part replaces 532166002. Price: $1.99 |
| 158 |
532437458 |
BRACKET.SHIFT.MOUNT This part replaces 532165589. Price: $5.99 |
| 159 |
532444304 |
HUB.SHIFT This part replaces 532165494. Price: $5.99 |
| 165 |
531149501 |
SERVICE KIT BRACKET BRACKET.PI This part replaces 532165623. Price: $4.99 |
| 166 |
532166880 |
SCREW Price: $4.99 |
| 168 |
532165492 |
BOLT.SHOULDER.5/16-18X Price: $8.99 |
| 169 |
532165580 |
PLATE.FASTENING.CROSS.SHAFT Price: $5.99 |
| 172 |
532165587 |
SHAFT Price: $12.99 |
| 173 |
532165934 |
BRACKET Price: $5.99 |
| 175 |
532165931 |
SPRING.BYPASS.CRD Price: $3.99 |
| 177 |
532165932 |
KEEPER Price: $6.99 |
| 178 |
532165933 |
KEEPER Price: $3.99 |
| 179 |
532120958 |
WASHER Price: $5.99 |
| 180 |
532165630 |
PULLEY.FLAT.IDLER Price: $27.99 |
| 181 |
532165797 |
BRKT.IDLER.GRD.DR.CRD Price: $2.99 |
| 182 |
529846301 |
SERVICE KIT KEEPER.BELT.2.5".V This part replaces 532165634. Price: $5.99 |
| 183 |
532165626 |
PULLEY.V-IDLER Price: $29.99 |
| 185 |
532165541 |
LINK Price: $5.99 |
| 186 |
532165614 |
HUB.TAPERED.ROUND.CRD Price: $4.99 |
| 188 |
532009151 |
SNAP BUSHING T This part replaces 532110436. Price: $2.99 |
