| Ref | Part Number | Description |
|---|
| 1 |
114-5401 |
ROLLER-WIEHLE, PLASTIC Price: $248.52 |
| 1 |
872050411 |
Bolt, Carriage 1/4-20 x 1-3/8 Price: $2.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
532127428 |
Seat (AYP part number) Price: $119.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
873800500 |
Locknut, Hex w/Ins 5/16-18 (AYP part number) Price: $2.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
532139888 |
Bolt, Shoulder 5/16-18 UNC (AYP part number) Price: $2.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
532145006 |
Clip, Push-In Hinged (AYP part number) Price: $2.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 8 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 9 |
532140551 |
Bracket, Pivot Seat (AYP part number) Price: $3.99 |
| 11 |
532413524 |
WASHER.13/32 X 1 X 1/2.11GUARD This part replaces 819133210. Price: $2.99 |
| 12 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 13 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $3.99 |
| 14 |
810040800 |
Washer Lock Hvy. Hlicl Spring 1/2 (AYP part number) Price: $3.99 |
| 15 |
819171912 |
Washer, 17/32 x 1-3/16 x 12 Ga. (AYP part number) Price: $3.99 |
| 16 |
532127018 |
Bolt, Shoulder (AYP part number) Price: $3.99 |
| 18 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 19 |
532121248 |
Bushing, Snap (AYP part number) Price: $3.99 |
| 20 |
532121250 |
Spring, Compression (AYP part number) Price: $3.99 |
| 21 |
532134300 |
Spacer, Split 28 Id. x .88 Lg. (AYP part number) Price: $3.99 |
| 22 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $4.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
