| Ref | Part Number | Description |
|---|
| 1 |
X-6-8 |
Screw-H.C. Price: Call Us |
| 2 |
X-21-1 |
Washer Price: Call Us |
| 3 |
52_041_09 |
Gasket-Intake Price: Call Us |
| 4 |
X-77-2 |
Nut Price: Call Us |
| 5 |
X-352-37 |
Stud Price: Call Us |
| 6 |
52_164_10 |
Manifold-Intake Price: Call Us |
| 7 |
52_445_02 |
Strap-Lifting Price: Call Us |
| 7 |
583348201 |
VALUE.VENT.15.19485924252 This part replaces 532414395. Price: $32.99 |
| 8 |
25_155_02 |
Connector-90? Price: Call Us |
| 8 |
583348301 |
MAGNET.19216324360 This part replaces 532414396. Price: $11.99 |
| 9 |
52_853_23 |
Kit-Carburetor w/Gasket (Incl. Ref. #10-33) Price: Call Us |
| 9 |
532414397 |
Magnet Holder Price: Call Us |
| 10 |
277069 |
Gasket Price: Call Us |
| 10 |
532415923 |
Pump Shaft/Bearing Kit Price: Call Us |
| 11 |
271030 |
Gasket Price: Call Us |
| 12 |
52_053_66 |
Carburetor Price: Call Us |
| 13 |
25_158_09 |
Bushing Price: Call Us |
| 13 |
583348501 |
LEVER.BYPASS.1A632029520 This part replaces 532414398. Price: $22.99 |
| 14 |
82_755_07 |
Kit-Governor Linkage (Incl. Ref. #13) Price: Call Us |
| 15 |
5218606 |
Arm-Governor Price: Call Us |
| 15 |
532414399 |
Sealing Cap 30 Price: Call Us |
| 16 |
25_086_27 |
Screw-Throttle Plate Price: Call Us |
| 16 |
532414400 |
Snap Ring C 35 Price: Call Us |
| 17 |
25_146_03 |
Plate-Choke Price: Call Us |
| 18 |
25_194_01 |
Ball-Choke Price: Call Us |
| 19 |
25_089_03 |
Spring-Choke Price: Call Us |
| 19 |
583348801 |
O-RING.1A.P10A.24311240100 This part replaces 532414401. Price: $5.99 |
| 20 |
52_144_18 |
Shaft-Throttle Lever Sea Price: Call Us |
| 20 |
583345001 |
SEAL.TC.153507 (24421153507) This part replaces 532414402. Price: $11.99 |
| 21 |
25_146_02 |
Plate-Throttle Price: Call Us |
| 22 |
25_089_02 |
Spring Price: Call Us |
| 23 |
25_368_01 |
Valve-Needle Price: Call Us |
| 24 |
25_089_04 |
Spring Price: Call Us |
| 25 |
25_086_26 |
Screw Price: Call Us |
| 26 |
52_090_12 |
Lever-Choke Price: Call Us |
| 27 |
25_368_03 |
Needle-Main Fuel Price: Call Us |
| 28 |
25_089_02 |
Spring Price: Call Us |
| 29 |
25_041_04 |
Bowl-Gasket Price: Call Us |
| 30 |
25_757_09 |
Kit-Float Price: Call Us |
| 31 |
25_104_01 |
Bowl Price: Call Us |
| 32 |
25_041_03 |
Gasket-Bowl Price: Call Us |
| 33 |
25_100_05 |
Screw-Bowl Price: Call Us |
| 33 |
532414403 |
Pump Shaft (Standard) Price: Call Us |
| 34 |
532414404 |
E-Ring 15 Price: Call Us |
| 35 |
532414405 |
Bearing 6202c3 Price: Call Us |
| 58 |
532414406 |
PIN.ROLL.640.22351060040 Price: $2.99 |
| 72 |
583349301 |
SEAL.19, 19216334280 This part replaces 532414407. Price: $17.99 |
| 76 |
532414408 |
Brake Lever Price: Call Us |
| 78 |
583349501 |
SPRING.RTN.BRK.168T2036180 This part replaces 532414409. Price: $17.99 |
| 80 |
583349601 |
PIN.SPRING.5*32.22351050032 This part replaces 532414410. Price: $3.99 |
| 81 |
583349701 |
O-RING.1A.P12.24311000120 This part replaces 532414411. Price: $5.99 |
| 82 |
583349801 |
PIN SPRING 4 16 22351040016 This part replaces 532414412. Price: $5.99 |
| 83 |
583349901 |
COLLAR.SPINE.1A646025300 This part replaces 532414413. Price: $11.99 |
| 84 |
583350001 |
PULLEY.L (1A646025810) This part replaces 532414414. Price: $44.99 |
| 85 |
532414415 |
Fan, Black Price: Call Us |
| 86 |
583350201 |
WASHER.WAVE.1A646083060 This part replaces 532414416. Price: $4.99 |
| 87 |
583350301 |
RING.SNAP.19215489090 This part replaces 532414417. Price: $4.99 |
| 90 |
583350401 |
PIN.3.0A.20 (22351030020) This part replaces 532414418. Price: $3.99 |
| 91 |
583351001 |
SEAL.OIL.16 This part replaces 532414419. Price: $9.99 |
| 95 |
583356901 |
PIN.SPR.3.0A This part replaces 532415850. Price: $3.99 |
| 96 |
583350601 |
PIN.ROLL.3.5 This part replaces 532414420. Price: $5.99 |
| 97 |
532414421 |
Control Lever Price: Call Us |
| 101 |
532414216 |
Lock Nut 10 Price: Call Us |
| 102 |
532414423 |
Washer 10 x 40 x 4 Price: Call Us |
| 103 |
532414424 |
Spring Price: Call Us |
| 105 |
532414425 |
Stud 10 x 60 Price: Call Us |
| 106 |
532414426 |
Sealing Cap 18 Price: Call Us |
| 107 |
532414427 |
Washer 10 x 36 x 2.8 Price: Call Us |
| 108 |
532414428 |
Collar 10 x 20 x 17 Price: Call Us |
