| Ref | Part Number | Description |
|---|
| 1 |
532185382 |
DECK SVC 50".BLACK This part replaces 532136457. Price: $549.99 |
| 1 |
75-5450 |
ARM WA - LIFT, RH Price: $822.45 |
| 2 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 2 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 3 |
237-78 |
O-RING Price: $3.85 |
| 3 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 4 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 4 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 5 |
237-21 |
O-RING Price: $0.70 |
| 5 |
532138457 |
BRACKET SWAY BAR Price: $9.99 |
| 6 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
75-5880 |
HOSE Price: $87.63 |
| 7 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 7 |
75-0770 |
HYD CYLINDER Price: $441.60 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 8 |
75-5330 |
CLAMP- HOSE Price: $31.69 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 9 |
67-1750 |
BUSHING Price: $0.92 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
75-5340 |
TUBE Price: $45.89 |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 12 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 12 |
75-6300 |
DISCONTINUED Price: Call Us |
| 13 |
328-9 |
SCREW-HH Price: $16.42 |
| 14 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 14 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 15 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 16 |
75-5210-03 |
BRACKET-SPRING, CENTER This part replaces 75-5210. Price: $94.91 |
| 17 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 17 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 18 |
328-7 |
SCREW-HH Price: $4.00 |
| 18 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 19 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 19 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 20 |
32151-48 |
E-RING Price: $1.41 |
| 20 |
532123713 |
SPRING TORSION Price: $6.99 |
| 21 |
282-4 |
SHACKLE Price: $32.98 |
| 21 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 22 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 22 |
532110452 |
NUT PUSH M Price: $2.99 |
| 23 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 23 |
532110509 |
SHIELD.DEFLECTOR.MOWER.50"BLK. Price: $27.99 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
532136320 |
RUNNER RH Price: $8.99 |
| 25 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 25 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 26 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 26 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 27 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 27 |
75-4550-03 |
SHAFT-LIFT, CENTER This part replaces 75-4550. Price: $259.44 |
| 28 |
532132823 |
IDLER SPRING SPACER Price: $5.99 |
| 28 |
75-5890 |
HOSE Price: $75.32 |
| 29 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 29 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 30 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 31 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 31 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532129861. Price: $14.99 |
| 32 |
75-5460 |
ARM WA - LIFT, LH Price: $796.56 |
| 33 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 33 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 34 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 34 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 35 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 36 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 36 |
75-5370 |
DISCONTINUED Price: Call Us |
| 37 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 37 |
532137166 |
STIFFENER ARM Price: $4.99 |
| 38 |
597024901 |
Keepers This part replaces 532137554. Price: $3.99 |
| 38 |
75-5380-03 |
CLAMP BRACKET This part replaces 75-5380. Price: $16.82 |
| 39 |
323-10 |
SCREW-HH Price: $0.89 |
| 39 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 40 |
532136572 |
PULLEY.DRIVEN.44" Price: $27.99 |
| 40 |
75-5420 |
DISCONTINUED Price: Call Us |
| 41 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 42 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 42 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 43 |
532136460 |
ARM.IDLER.SEC.44" Price: $5.99 |
| 43 |
75-5360 |
PIN-CYLINDER Price: $72.33 |
| 44 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 44 |
75-3040 |
CARRIER FRAME WA *B Price: $1,352.49 |
| 45 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 45 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 46 |
163-3535 |
CYLINDER-HYDRAULIC This part replaces 75-0780. Price: $582.35 |
| 46 |
582740701 |
BOLT This part replaces 874760628. Price: $4.99 |
| 47 |
532137200 |
COVER MANDRELL Price: $21.99 |
| 47 |
75-5900 |
HOSE Price: $78.45 |
| 48 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 48 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 49 |
532136574 |
COVER.MANDREL.LH.44" Price: $19.99 |
| 49 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 50 |
532137272 |
ARM.IDLER.PRIMARY Price: $4.99 |
| 50 |
99-5301 |
RETAINER KIT This part replaces 32151-94. Price: $7.10 |
| 51 |
532137273 |
SPRING.SEC.44"VEN Price: $6.99 |
| 51 |
75-6310 |
DISCONTINUED Price: Call Us |
| 52 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 52 |
532139245 |
PULLEY IDLER Price: $32.99 |
| 53 |
532137789 |
SHIELD IDLER Price: $4.99 |
| 53 |
75-5410 |
BRACKET-ARM Price: $12.57 |
| 54 |
110-0009 |
JOINT ARM ASM This part replaces 75-3010. Price: $199.32 |
| 54 |
532139573 |
V-BELT.PRMRY 46/50 VENT.BLK BK Price: $44.99 |
| 55 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 55 |
532138255 |
BELT, V GROUND DRIVE 95 25 Price: $34.99 |
| 56 |
323-12 |
SCREW-HH Price: $1.14 |
| 56 |
532138687 |
SPRING Price: $3.99 |
| 57 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 57 |
532136577 |
BAR.ASM.GUAGE.WHEEL Price: $9.99 |
| 58 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 58 |
532105455 |
WHEEL.GAUGE.BLK.4.93 Price: $14.99 |
| 59 |
325-4 |
SCREW-HH Price: $0.95 |
| 59 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 60 |
532139031 |
PIN.CLEVIS Price: $4.99 |
| 60 |
75-5910 |
HOSE Price: $69.05 |
| 61 |
532136573 |
BRACKET.GUAGE.WHEEL Price: $4.99 |
| 61 |
75-5320 |
PIN - CYLINDER,1.0 DIA Price: $16.09 |
| 62 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 62 |
93-6687 |
DECAL-NO STEP This part replaces 36-3400. Price: $14.45 |
| 63 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 63 |
75-5300 |
ROD - HOSE SUPPORT Price: $27.99 |
| 64 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 64 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 65 |
532102403 |
IDLER-FLAT T Price: $34.99 |
| 66 |
532156009 |
KEEPER, BELT IDLER 44/50 This part replaces 532139622. Price: $5.99 |
| 67 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $7.99 |
| 96 |
531154101 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532132273. Price: $12.99 |
| 97 |
819171416 |
Washer 17/32 x 7/8 x 16 Ga. Price: $3.99 |
| 98 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 99 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 100 |
819171512 |
Washer 17/32 x 15/16 x 12 Ga. Price: $3.99 |
