| Ref | Part Number | Description |
|---|
| 1 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 1 |
532189741 |
CONTROL.WALK.EZ.BLACK Price: $43.99 |
| 2 |
532197168 |
KIT.CONTL.ASM.CASE.HALVES.GREY This part replaces 532188279. Price: $44.99 |
| 2 |
60-3520 |
O-RING Price: $4.57 |
| 3 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 3 |
532187353 |
PULLEY.CAM.DRIVE.CONTROL.HV Price: $6.99 |
| 4 |
110-5227 |
HUB-PUMP This part replaces 93-2589. Price: $38.93 |
| 4 |
532425583 |
LEVER.SHORT.BLACK.EZ.WALK This part replaces 532190039. Price: $14.99 |
| 5 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 5 |
532197168 |
KIT.CONTL.ASM.CASE.HALVES.GREY This part replaces 532188278. Price: $44.99 |
| 6 |
532181698 |
SCREW, PHILLIPS HEAD 10 X 5/8 Price: $3.99 |
| 7 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 7 |
532400723 |
BRACKET.DRIVE.CONTROL.MOUNT.BL This part replaces 532187097. Price: $4.99 |
| 8 |
532186297 |
EZ WALK SNAP COVER PLATE Price: $5.99 |
| 8 |
80-8650 |
COUPLING-DRIVE Price: $32.04 |
| 9 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 9 |
532190284 |
CABLE, DRIVE CONTROL Price: $39.99 |
| 10 |
532189074 |
DECAL.DRIVE.CONTROL.HV Price: $5.99 |
| 10 |
93-2170-03 |
PUMP ADAPTER ASM This part replaces 93-2170. Price: $171.94 |
| 11 |
33114-020 |
SCREW-HH Price: $0.28 |
| 11 |
532185913 |
DECAL Price: $5.99 |
| 12 |
33114-030 |
SCREW-HH Price: $0.50 |
| 12 |
532187653 |
SCREW Price: $4.99 |
| 13 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 13 |
532414282 |
KIT.TRANSMISION.REPLACE.180868 This part replaces 532188645. Price: $109.99 |
| 14 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 14 |
532194128 |
PULLEY This part replaces 532189408. Price: $17.99 |
| 15 |
33115-040 |
SCREW-HH Price: $1.22 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $3.99 |
| 16 |
532414284 |
KIT.ROD.CONNECTING.REPL.161584 This part replaces 532161584. Price: $32.99 |
| 16 |
93-2586 |
DISCONTINUED Price: Call Us |
| 17 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 17 |
532409616 |
SPRING EXTENSION This part replaces 532161602. Price: $5.99 |
| 18 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 18 |
532418835 |
SPRING.SELECTOR.SPT.21.BZP This part replaces 532190794. Price: $5.99 |
| 19 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
532189808 |
KNOB.S/P.RWGD.EXT.ERGO.GREY This part replaces 532190622. Price: $2.99 |
| 20 |
3274-1 |
SCREW-HSH Price: $5.52 |
| 20 |
812000022 |
E-RING Price: $3.99 |
| 21 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 21 |
532169920 |
BEARING SUPPORT.ASM This part replaces 532163365. Price: $14.99 |
| 22 |
353-988 |
PLUG-HEX Price: $10.61 |
| 22 |
532169911 |
BEARING, BALL Price: $11.99 |
| 23 |
532161118 |
RETAINER DRIVE ASM. STMP. This part replaces 532164555. Price: $3.99 |
| 23 |
93-2252 |
HOSE ASSY - HYD Price: $119.96 |
| 24 |
532057808 |
SCREW Price: $1.99 |
| 24 |
99-1905 |
HOSE-INLET, PUMP This part replaces 94-8174. Price: $53.05 |
| 25 |
532400783 |
COVER.DRIVE.21.RWGD.MO This part replaces 532190514. Price: $9.99 |
| 25 |
94-6384 |
HOSE ASM Price: $64.68 |
| 26 |
532750634 |
SCREW Price: $2.99 |
| 26 |
94-5355 |
DISCONTINUED Price: Call Us |
| 27 |
596040101 |
Washers This part replaces 532052160. Price: $2.99 |
| 27 |
94-1332 |
HOSE ASM Price: $192.16 |
| 28 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 28 |
95-0533 |
DISCONTINUED Price: Call Us |
| 29 |
237-79 |
O-RING Price: $5.46 |
| 29 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532189403. Price: $5.99 |
| 30 |
532175104 |
DISC.DRIVE.21.EZ-WALK Price: $5.99 |
| 31 |
237-22 |
O-RING Price: $2.43 |
| 31 |
532184172 |
SEAL.PINION Price: $5.99 |
| 32 |
237-65 |
O-RING Price: $2.50 |
| 32 |
532193139 |
KIT.WHL.9X2.RAD.BLK(SERV ONLY) This part replaces 532180774. Price: $54.99 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 33 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 34 |
237-81 |
O-RING Price: $2.76 |
| 34 |
532150182 |
CAP.HUB.ARC.SPOKE.8".LP This part replaces 532180626. Price: $3.99 |
| 35 |
532403102 |
SHAFT.ASM.REAR.TORQUE.BZP.8 This part replaces 532191205. Price: $29.99 |
| 35 |
94-5356 |
HOSE ASM Price: $128.89 |
| 36 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 36 |
532407175 |
SHAFT.ASM.FRONT.TORQUE.BZP. This part replaces 532164550. Price: $22.99 |
| 37 |
532161463 |
RETAINER.FRONT.SHAFT Price: $9.99 |
| 37 |
98-4606 |
HOSE ASM Price: $56.35 |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 38 |
532163409 |
SCREW Price: $3.99 |
| 39 |
237-42 |
O-RING Price: $2.78 |
| 39 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 40 |
532150339 |
WHEEL.8X2.PR.LP.RADII.BLK Price: $32.99 |
| 40 |
94-6385 |
DISCONTINUED Price: Call Us |
| 41 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 41 |
532414860 |
KIT.PINION.ASM This part replaces 532188330. Price: $76.99 |
| 42 |
33113-050 |
SCREW-HH Price: $0.62 |
| 42 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 43 |
340-94 |
ADAPTER Price: $36.83 |
| 43 |
532414860 |
KIT.PINION.ASM This part replaces 532188331. Price: $76.99 |
| 44 |
94-6383 |
HOSE ASM Price: $53.36 |
| 45 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 45 |
532175098 |
PAWL.DRIVE.21.EZ-WALK Price: $4.99 |
| 46 |
532188291 |
SPRING, TORSION Price: $3.99 |
| 47 |
532067725 |
WASHER FLUT Price: $5.99 |
| 48 |
532175105 |
RETAINER.DRIVE.21.EZ-WALK.LT Price: $5.99 |
| 49 |
532175103 |
GEAR, PINION Price: $10.99 |
| 50 |
532175102 |
RETAINER, DRIVE, RH Price: $5.99 |
| 51 |
532187530 |
CASE, LOWER Price: $10.99 |
| 52 |
532187531 |
CASE, UPPER Price: $22.99 |
| 53 |
532187532 |
GEAR.24.TOOTH.WALK.MOWER Price: $11.99 |
| 54 |
532187533 |
SHAFT INPUT Price: $24.99 |
| 55 |
532183505 |
WIRE, FORMED (15966) Price: $5.99 |
| 56 |
532183506 |
BEARING Price: $5.99 |
| 57 |
532183508 |
SEAL.OUTPUT.SHAFT Price: $9.99 |
| 58 |
532183509 |
WASHER Price: $3.99 |
| 59 |
532183511 |
BUSHING Price: $4.99 |
| 60 |
532191249 |
RP.SHAFT.OUTPUT.RGD.VS/EZ Price: $54.99 |
| 61 |
532183513 |
SCREW Price: $3.99 |
