| Ref | Part Number | Description |
|---|
| 1 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 1 |
X-140-1 |
Screw-Sltd. Hd. Price: Call Us |
| 2 |
41_853_07 |
Kit-Carburetor Price: Call Us |
| 2 |
596671501 |
Washers This part replaces 539101949. Price: $2.99 |
| 3 |
25_158_08 |
Bushing Price: Call Us |
| 3 |
539106791 |
HEX BOLT 3/8 X 1" Price: $2.99 |
| 4 |
210223 |
Gasket-Carburetor Price: Call Us |
| 4 |
539110071 |
TORSION SPRING, DECK LIFT Price: $6.99 |
| 5 |
41_053_27 |
Carb. Assy. (For information only-not available separately) Price: Call Us |
| 5 |
539110160 |
SPRING, DECK ROD RIGHT Price: $5.99 |
| 6 |
41_041_11 |
Gasket-Air Cleaner Price: Call Us |
| 6 |
539110161 |
SPRING, DECK ROD LEFT Price: $8.99 |
| 7 |
25_155_02 |
Connector-90? Price: Call Us |
| 7 |
539110205 |
DECK LIFT ASM PAINTED Price: $349.99 |
| 8 |
25_086_27 |
Screw-Throttle Plate Price: Call Us |
| 8 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 9 |
41_146_16 |
Plate-Choke Price: Call Us |
| 9 |
539100032 |
BUSHING, FLANGED NYLON Price: $5.99 |
| 10 |
25_194_02 |
Ball-Choke Friction Price: Call Us |
| 10 |
539110292 |
FOOT PEDAL Price: $17.99 |
| 11 |
25_089_06 |
Spring-Choke Friction Price: Call Us |
| 11 |
539110308 |
FOOT PAD, NON-SLIP Price: $3.99 |
| 12 |
25_089_02 |
Spring Price: Call Us |
| 12 |
539110275 |
FOOT LEVER WELDED This part replaces 539110266. Price: $54.99 |
| 13 |
25_368_03 |
Needle-Main Fuel Price: Call Us |
| 13 |
539110287 |
CASTER CASTING, RIGHT, PAINTED Price: $119.99 |
| 14 |
25_086_26 |
Screw Price: Call Us |
| 14 |
539110288 |
CASTER CASTING LEFT, PAINTED Price: $84.99 |
| 15 |
25_089_04 |
Spring Price: Call Us |
| 15 |
539110295 |
SPRING, PEDAL, LIFT Price: $4.99 |
| 16 |
25_089_02 |
Spring Price: Call Us |
| 16 |
539110306 |
DECK LIFT ROD Price: $7.99 |
| 17 |
25_368_02 |
Needle-Idle Fuel Price: Call Us |
| 17 |
596739901 |
Yoke This part replaces 539977465. Price: $27.99 |
| 18 |
41_144_18 |
Shaft-Throttle Lever w/Seal Price: Call Us |
| 18 |
539990155 |
NUT 3/8F Price: $2.99 |
| 19 |
25_146_05 |
Plate-Throttle Price: Call Us |
| 19 |
539113239 |
CONNECTOR, DECK LIFT Price: $14.99 |
| 20 |
41_090_22 |
Shaft-Choke Price: Call Us |
| 20 |
539113931 |
HEIGHT PLATE, DECK Price: $24.99 |
| 21 |
25_041_04 |
Bowl-Gasket Price: Call Us |
| 21 |
539916459 |
RETAINER Price: $3.99 |
| 22 |
25_757_09 |
Kit-Float Price: Call Us |
| 22 |
539977703 |
CLEVIS PIN 3/8 X 1 1/8 Price: $4.99 |
| 23 |
25_104_01 |
Bowl Price: Call Us |
| 24 |
25_041_03 |
Gasket-Bowl Price: Call Us |
| 25 |
25_100_05 |
Screw-Bowl Price: Call Us |
