CARBURETOR 2
Parts (34)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 104-0917 | YOKE Price: $160.81 |
| 1 | 587106701 | NEEDS DESCRIPTION Price: Call Us |
| 2 | 104-0918 | CROSS AND BEARING KIT Price: $96.56 |
| 2 | 505307901 | SCREW Price: $2.99 |
| 3 | 104-0920 | YOKE-INBOARD Price: $141.80 |
| 3 | 506746001 | BRACKET Price: $8.99 |
| 4 | 104-0921 | PIN-SPRING Price: $2.31 |
| 4 | 506741201 | SWIVEL This part replaces 516597701. Price: $4.99 |
| 5 | 104-0922 | TUBE-PROFILE, INNER Price: $88.38 |
| 5 | 506746101 | WASHER Price: $2.99 |
| 6 | 104-0925 | TUBE-PROFILE, OUTER Price: $106.30 |
| 6 | 587642901 | NEEDS DESCRIPTION Price: Call Us |
| 7 | 516523601 | RING This part replaces 506738601. Price: $2.99 |
| 7 | 77-4760 | CHAIN-SAFETY Price: $18.38 |
| 8 | 104-0926 | GUARD-PTO Price: $168.35 |
| 8 | 512373401 | NEEDLE Price: $5.58 |
| 9 | 104-0927 | PTO GUARD ASM Price: $177.19 |
| 9 | 513301601 | SPRING Price: $1.99 |
| 10 | 513437701 | WASHER Price: $1.99 |
| 11 | 513437801 | O-RING Price: $1.99 |
| 12 | 505308401 | RING PACKING Price: $3.99 |
| 13 | 506745101 | GASKET Price: $6.99 |
| 14 | 506689801 | DIAPHRAGM Price: $3.99 |
| 15 | 513410801 | BODY-A Price: $49.99 |
| 16 | 574012501 | RP_SCREEN (RPLS 331081380) This part replaces 520957001. Price: $3.99 |
| 17 | 521085401 | VALVE INLET Price: $11.99 |
| 18 | 513410701 | SPRING Price: $1.99 |
| 19 | 520977201 | LEVER Price: $4.99 |
| 20 | 520977401 | PIN Price: $4.99 |
| 21 | 505306101 | SCREW Price: $2.99 |
| 23 | 505306801 | DIAPHRAGM Price: $12.99 |
| 24 | 506740901 | BODY Price: $19.99 |
| 25 | 505306701 | PUMP Price: $7.99 |
| 27 | 506741101 | SCREW This part replaces 516544001. Price: $2.99 |
