| Ref | Part Number | Description |
|---|
| 1 |
108-6715 |
GAUGE BAR ASM Price: $148.12 |
| 1 |
532130970 |
Deck Asm Mower 42" (AYP part number) Price: $3.33 |
| 2 |
29-9100 |
BRUSH AND HANDLE ASM Price: $58.15 |
| 2 |
532130969 |
V-belt Mower 42" (AYP part number) Price: $22.99 |
| 3 |
532110485 |
Bearing Ball Mandrel (AYP part number) Price: $7.99 |
| 4 |
115-0803 |
ROLLER REBUILD TOOL KIT Price: $122.41 |
| 4 |
532128774 |
Housing Mandrel Vented Price: $22.99 |
| 5 |
125-5610 |
PAPER-REEL, TORO (10 PACK) Price: $6.02 |
| 5 |
532137646 |
KIT MANDREL W/NUT This part replaces 532133172. Price: $17.99 |
| 6 |
140-5531 |
SHIM-TORO REEL (.002IN) This part replaces 125-5611. Price: $6.67 |
| 6 |
532129895 |
Bearing Ball #6204 (AYP part number) Price: $6.99 |
| 7 |
131-6828 |
INDICATOR-ANGLE Price: $69.10 |
| 8 |
532140296 |
WASHER.BLADE This part replaces 532129962. Price: $2.99 |
| 9 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 10 |
532850857 |
Bolt 3/8 - 24 x 1.25 Gr 8 Patched (AYP part number) Price: $1.99 |
| 11 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532128961. Price: $3.99 |
| 12 |
532130968 |
Shield Deflector 42" (AYP part number) Price: $22.99 |
| 13 |
532131491 |
Rod Hinge 42" (AYP part number) Price: $1.99 |
| 14 |
532177563 |
BRKT, DEFL. MOWER This part replaces 532131267. Price: $2.99 |
| 15 |
532110452 |
Nut PushPhos & Oil (AYP part number) Price: $1.99 |
| 16 |
532123713 |
Spring Torsion Deflector 42" (AYP part number) Price: $3.99 |
| 17 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga (AYP part number) Price: $5.99 |
| 18 |
532105304 |
Cap Sleeve (AYP part number) Price: $2.99 |
| 19 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 20 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 21 |
532124670 |
Retainer Spring (AYP part number) Price: $5.99 |
| 22 |
532127218 |
Link Front (AYP part number) Price: $9.99 |
| 23 |
873350800 |
Nut Jam Hex 1/2 - 13 Unc (AYP part number) Price: $1.99 |
| 24 |
532175689 |
TRUNNION This part replaces 532130171. Price: $2.99 |
| 25 |
539101331 |
NUT 1/2-13 HEX NYLOC ZD This part replaces 873800800. Price: $1.99 |
| 26 |
532127224 |
Link Lift Rh (AYP part number) Price: $22.99 |
| 27 |
532135563 |
Pin Spring Sltd 5/16 (AYP part number) Price: $2.99 |
| 28 |
532178024 |
BAR SWAY DECK This part replaces 532130833. Price: $5.99 |
| 29 |
532127223 |
Link Lift Lh (AYP part number) Price: $23.91 |
| 30 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873360700. Price: $3.99 |
| 31 |
532110447 |
Trunnion Lift (AYP part number) Price: $9.99 |
| 32 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873710700. Price: $3.99 |
| 33 |
532151785 |
CAM ROLLER KIT This part replaces 532133844. Price: $27.99 |
| 34 |
817580520 |
Screw Thdrol. 5/16-18 x 1.25 (AYP part number) This part replaces 532078158. Price: $2.99 |
| 35 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 36 |
532129861 |
Pulley Mandrel 42" (AYP part number) Price: $17.99 |
| 37 |
532139729 |
KIT.NUT.FLANGE This part replaces 873050900. Price: $4.99 |
| 38 |
872110622 |
Bolt, Carriage 3/8 - 16 x 2-3/4 (AYP part number) Price: $0.99 |
| 39 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 40 |
532173438 |
PULLEY.IDLER.FLAT This part replaces 532131494. Price: $14.99 |
| 41 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 42 |
819131612 |
Washer 13/32 X 1 X 12 Ga (AYP part number) This part replaces 819131616. Price: $3.99 |
| 45 |
873680600 |
Nut Crownlock 3/8 - 16 Unc Price: $1.99 |
| 46 |
872110616 |
Bolt Rdhd Sqnk 3/8 - 16 x 2 (AYP part number) Price: $3.99 |
| 47 |
532133835 |
Fastener Christmas Tree (AYP part number) Price: $3.99 |
| 54 |
532131950 |
Spring Extension Price: $4.99 |
| 58 |
532131857 |
Guard Mandrel Lh (AYP part number) Price: $3.33 |
| 60 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 63 |
817720410 |
Screw Hex Thd Cut 1/4 - 20 x 5/8 T (AYP part number) Price: $5.99 |
| 70 |
532132823 |
Spacer, Spring Stop Idler Price: $4.99 |
| 71 |
532134753 |
Stiffner, Bracket (AYP part number) Price: $5.99 |
| 74 |
812000022 |
Ring E #5166-87 (AYP part number) Price: $3.99 |
| 75 |
819292016 |
Washer 29/32 x 1 - 1/4 x 16 Ga (AYP part number) Price: $3.99 |
| 76 |
532131925 |
Shaft Asm Lift (AYP part number) Price: $3.33 |
| 77 |
532121002 |
Lever Asm Lift (AYP part number) Price: $74.99 |
| 78 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 874780624. Price: $3.99 |
| 79 |
532121006 |
Rod Asm Lever (AYP part number) Price: $19.99 |
| 80 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 81 |
532124562 |
Plunger Lever Lift (AYP part number) Price: $3.33 |
| 82 |
532109413 |
Button Plunger Black (AYP part number) Price: $2.99 |
| 83 |
532125631 |
Grip Handle Bicycle (AYP part number) Price: $3.99 |
| 84 |
532110810 |
Trunnion Dpt Stop Price: $14.99 |
| 85 |
819151216 |
Washer 15/32 x 3/4 x 16 Ga (AYP part number) Price: Call Us |
| 86 |
812000037 |
Ring Klip #T5304-37 (AYP part number) Price: $3.99 |
| 87 |
532110807 |
Nut Special (AYP part number) Price: $3.99 |
| 88 |
819131016 |
Washer 13/32 x 5/8 x 16 Ga (AYP part number) Price: $3.99 |
| 89 |
876020308 |
Pin Cotter 3/32 x 1/2 (AYP part number) Price: $1.99 |
| 90 |
532110729 |
Rod Adj Lift (AYP part number) Price: $18.99 |
| 91 |
532121891 |
Knob Infinite 3/8 - 16 Unc Black (AYP part number) Price: $3.99 |
| 92 |
532175747 |
BRACKET ASM, ROLLER This part replaces 532132273. Price: $7.99 |
| 93 |
819171416 |
Washer 17/32 x 7/8 x 16 Ga. (AYP part number) Price: $2.99 |
| 94 |
873680600 |
Nut, Crownlock 3/8 - 16 Price: $1.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $3.99 |
| 96 |
532132264 |
Roller, Nose Price: $27.99 |
| 97 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
