Service Update
Parts (58)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 61-0590-01 | SCRAPER ROLLER This part replaces 61-0590. Price: $48.66 |
| 2 | 323-7 | SCREW-HH Price: $0.65 |
| 2 | 503584601 | SCREW Price: $2.99 |
| 3 | 121-4600 | NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 3 | 505316754 | DIAPHRAGM COVER Price: $3.99 |
| 4 | 503896701 | DIAPHRAGM Price: $44.99 |
| 5 | 504350906 | GASKET Price: $9.99 |
| 6 | 537306201 | BUCKLE Price: $4.99 |
| 7 | 537407401 | SHAFT Price: $7.99 |
| 8 | 537407501 | SHAFT Price: $22.99 |
| 9 | 537407701 | VALVE Price: $8.99 |
| 10 | 501468701 | SCREW Price: $6.99 |
| 11 | 501468701 | SCREW Price: $6.99 |
| 12 | 537406801 | CHOKE FLAP Price: $6.99 |
| 13 | 537406901 | SHAFT Price: $5.99 |
| 14 | 537407201 | ROD Price: $11.99 |
| 15 | 537407001 | SPRING Price: $4.99 |
| 16 | 537406701 | SLEEVE Price: $2.99 |
| 17 | 505520125 | FULCRUM PIN Price: $6.99 |
| 18 | 505316717 | SCREW Price: $6.99 |
| 19 | 505520127 | LEVER Price: $4.99 |
| 20 | 503563401 | INLET NEEDLE Price: $14.99 |
| 21 | 537407901 | JET Price: $7.99 |
| 22 | 537408501 | SPRING Price: $4.99 |
| 23 | 503574201 | WELCH PLUG Price: $6.99 |
| 24 | 503800401 | NOZZLE Price: $3.99 |
| 25 | 537408301 | SCREW Price: $7.99 |
| 26 | 537406601 | SLEEVE Price: $2.99 |
| 27 | 502119801 | CLIPS Price: $7.99 |
| 28 | 537408101 | GASKET Price: $9.99 |
| 29 | 501468501 | BALL Price: $6.99 |
| 30 | 501468401 | SPRING Price: $6.99 |
| 31 | 503935101 | THROTTLE FLAP Price: $7.99 |
| 32 | 530035015 | SCREW SHUTTERS Price: $2.99 |
| 33 | 537408401 | SPRING Price: $3.99 |
| 34 | 537409201 | LEVER Price: $3.99 |
| 35 | 537408601 | SPRING Price: $3.99 |
| 36 | 537409001 | NIPPLE Price: $2.08 |
| 37 | 504210049 | SPRING, H-NEEDLE Price: $11.99 |
| 39 | 503913901 | LIMITER CAP Price: $2.99 |
| 40 | 537408001 | SLEEVE Price: $6.99 |
| 41 | 501666101 | FUEL INLET SCREEN Price: $12.99 |
| 42 | 503914001 | LIMITER CAP Price: $4.99 |
| 44 | 530035293 | NEEDLE SPRING This part replaces 504210050. Price: $2.99 |
| 45 | 537409101 | NIPPLE Price: $3.99 |
| 46 | 503915401 | CAP Price: $7.99 |
| 47 | 537240801 | SLEEVE Price: $7.99 |
| 48 | 502119801 | CLIPS Price: $7.99 |
| 49 | 537407101 | LEVER Price: $3.99 |
| 50 | 501468701 | SCREW Price: $6.99 |
| 51 | 537407601 | PLATE Price: $3.99 |
| 52 | 501468701 | SCREW Price: $6.99 |
| 53 | 504130807 | PUMP DIAPHRAGM Price: $27.99 |
| 54 | 504130906 | GASKET Price: $9.99 |
| 55 | 537407301 | COVER Price: $5.99 |
| 56 | 501466901 | SCREW Price: $7.99 |
| 57 | 503564201 | SPRING Price: $9.99 |
| 58 | 537408201 | SCREW Price: $14.99 |
