| Ref | Part Number | Description |
|---|
| 0 |
632044A |
CARBURETOR This part replaces 631690. Price: $78.00 |
| 1 |
532174619 |
CHASSIS STAMPING Price: $84.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $24.99 |
| 2 |
631767 |
SPRING This part replaces 632016. Price: $1.25 |
| 3 |
631972 |
WASHER Price: $1.25 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 9 |
532433353 |
DASH Price: $29.99 |
| 10 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $8.99 |
| 13 |
532181719 |
PANEL DASH RH Price: $8.99 |
| 16 |
632527 |
FUEL FITTING Price: $6.03 |
| 17 |
532406179 |
HOOD.BLACK.ALPHA Price: $89.99 |
| 18 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 24 |
874780616 |
BOLT Price: $3.99 |
| 25 |
631700 |
FLOAT BOWL Price: $2.99 |
| 25 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 26 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
532426741 |
GRILLE.ASM.ALPHA Price: $119.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
532195402 |
LENS.ALPHA.BAR.LT Price: $11.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
532194589 |
FENDER.LTST.W/SHFT.CUP.BLACK Price: $119.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
532136619 |
BRACKET FENDER Price: $3.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 33 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532179716. Price: $17.99 |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532179717. Price: $17.99 |
| 35 |
730167 |
PRIMER ASSY Price: $7.17 |
| 35 |
872110606 |
BOLT Price: $2.99 |
| 37 |
817490508 |
SCREW LT Price: $3.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $5.99 |
| 39 |
532187568 |
BRACKET.PIVOT.ALPHA.LT Price: $11.99 |
| 64 |
532154798 |
DASH LOWER Price: $22.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 205 |
817490608 |
SCREW LT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $3.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 212 |
532187569 |
INSERT.ALPHA.REFLECTIVE.LT. Price: $7.99 |
| 278 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 532005479 |
PLUG |
BUTTON T Price: $2.99 532005479 |
