| Ref | Part Number | Description |
|---|
| 1 |
131-4579 |
HOUSING ASM Price: $211.99 |
| 2 |
114-7963-01 |
BAFFLE-FRONT Price: $35.99 |
| 6 |
139-8982 |
BAFFLE-REAR This part replaces 114-7961. Price: $14.99 |
| 7 |
132-4501 |
CHUTE-RECYCLE Price: $28.99 |
| 8 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 9 |
112-6416 |
BRACKET-COVER Price: $2.49 |
| 10 |
137-4795 |
SCREW This part replaces 99-8445. Price: $0.29 |
| 11 |
136-8672 |
HINGE PIN-DEFLECTOR This part replaces 99-5291. Price: $2.99 |
| 12 |
99-5293 |
SPRING-TORSION Price: $9.99 |
| 13 |
115-8449 |
DEFLECTOR-SIDE Price: $7.99 |
| 14 |
115-8447 |
CHUTE-DISCHARGE, SIDE Price: $15.99 |
| 15 |
114-7960 |
DEFLECTOR-RECYCLE Price: $13.99 |
| 16 |
114-7958 |
KNOB-RECYCLE Price: $3.49 |
| 17 |
114-7959 |
LATCH-RECYCLE Price: $4.99 |
| 18 |
117-1031 |
SPRING-COMPRESSION Price: $2.79 |
| 19 |
32104-120 |
SCREW-PPH Price: $1.49 |
| 20 |
137-9139 |
REAR DOOR ASM This part replaces 121-5776. Price: $23.99 |
| 21 |
115-2859 |
SPRING-TORSION Price: $4.89 |
| 22 |
114-7924 |
SPRING-TORSION Price: $3.29 |
| 23 |
112-6400 |
PORT-WASHOUT Price: $4.49 |
| 24 |
112-6401 |
COUPLING-HOSE, WASHOUT PORT Price: $2.39 |
| 26 |
112-6438 |
WASHER-SEAL, WASHOUT PORT Price: $1.19 |
| 27 |
3254-5 |
WASHER-LOCK Price: $0.49 |
| 28 |
3218-6 |
NUT-JAM Price: $0.61 |
| 30 |
114-7987 |
BUMPER Price: $11.99 |
| 31 |
105-6849 |
SCREW-FORMING, THREAD Price: $0.69 |
| 32 |
130-6708 |
COVER-BELT, FRONT Price: $13.99 |
| 33 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 34 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 35 |
133-1973 |
COVER-BELT, FRONT Price: $5.69 |
| 36 |
131-0837 |
SCREW-SHOULDER, HHF Price: $1.69 |
| 42 |
125-5026 |
DECAL Price: $1.89 |
