| Ref | Part Number | Description |
|---|
| 1 |
26-1490 |
RH CASTOR ARM ASM Price: $643.06 |
| 1 |
428142 |
Link, Deck Lift - LH Price: Call Us |
| 2 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 2 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 3 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 3 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
3-1365 |
CHAIN This part replaces 21-3160. Price: $72.97 |
| 4 |
43086 |
BUSHING, SPEED ADJUSTMENT LEVER Price: Call Us |
| 5 |
04061-07 |
Pin, Cotter 3/16 x 1.0" Price: Call Us |
| 5 |
26-1890 |
DISCONTINUED Price: Call Us |
| 6 |
04040-07 |
Flatwasher, 1/2 - .531 x 1.062 x .095 Price: Call Us |
| 6 |
3217-7 |
NUT-HEX Price: $0.28 |
| 7 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 7 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 8 |
39-3340-01 |
BRACKET-ARM CLAMP This part replaces 39-3340. Price: $101.90 |
| 8 |
431072 |
Joint, Swivel Price: Call Us |
| 9 |
452962 |
Lift Bellcrank Weldment Price: Call Us |
| 9 |
93-9838-03 |
SHROUD-SHAFT, DRIVE This part replaces 26-2250. Price: $56.70 |
| 10 |
04041-08 |
Flatwasher, 3/4 (.766 x 1.250 x .060) Price: Call Us |
| 10 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 11 |
04050-02 |
RETAINING RING, 3/4" EXTERNAL "E" Price: Call Us |
| 11 |
5-2942 |
SHACKLE Price: $16.99 |
| 12 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 12 |
48114-04 |
GREASE FITTING, STR. 1/4-28 SELF TAP. Price: Call Us |
| 13 |
21-3770-01 |
LIFT STRAP-DECK, RIGHT REAR This part replaces 21-3770. Price: $15.29 |
| 13 |
428143 |
Link, Deck Lift - RH Price: Call Us |
| 14 |
3217-8 |
NUT-HEX Price: $1.34 |
| 14 |
485351 |
Pin Assembly, Deck Height Price: Call Us |
| 15 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 15 |
43986 |
Spacer, Pusharm - Axle Price: Call Us |
| 16 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 16 |
462769 |
Pusharm Assembly, LH Price: Call Us |
| 17 |
26-1900 |
DISCONTINUED Price: Call Us |
| 17 |
462770 |
Pusharm Assembly, RH Price: Call Us |
| 18 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 18 |
43985 |
Spacer, Pusharm - Deck Price: Call Us |
| 19 |
3217-9 |
NUT-HH Price: $0.37 |
| 19 |
424489 |
Bracket, Push Arm Link Price: Call Us |
| 20 |
04001-145 |
Bolt, Hex Head 1/2-13 x 3-1/2" Price: Call Us |
| 20 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 21 |
04001-52 |
Bolt, Hex Hd. 1/2-13 x 2-1/2" (lower) Price: Call Us |
| 21 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
04001-49 |
Bolt, Hex Head 5/16-18 x 3.00" Price: Call Us |
| 22 |
3233-1 |
SCREW-CARR Price: $1.42 |
| 23 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 23 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 24 |
39-7450-01 |
BRACKET-CLAMP, LH This part replaces 39-7450. Price: $100.55 |
| 24 |
44220 |
Rod, Deck Lift Price: Call Us |
| 25 |
04040-09 |
Flatwasher, 5/8" (.656 x 1.312 x .095") Price: Call Us |
| 25 |
39-3330-01 |
PLATE-CLAMP, CASTOR ARM This part replaces 39-3330. Price: $36.10 |
| 26 |
325-13 |
SCREW-HH Price: $3.57 |
| 27 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 28 |
26-1580 |
SPACER 1/2 IN Price: $9.91 |
| 29 |
94-1291 |
BUSHING This part replaces 28-9290. Price: $10.99 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
26-1430 |
LH CASTOR ARM ASM Price: $643.06 |
| 32 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 33 |
99-5690 |
CASTOR FORK ASM This part replaces 26-1560. Price: $183.50 |
| 34 |
21-3870 |
AXLE ASM Price: $14.07 |
| 35 |
99-5693 |
BEARING RETAINER W/WASHER This part replaces 40-9390. Price: $18.61 |
| 36 |
21-1030 |
SPANNER BUSHING Price: $17.87 |
| 38 |
21-3860 |
WHEEL Price: $85.23 |
| 39 |
21-3850 |
ROLLER BRG W/46-8960 Price: $15.21 |
| 40 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 41 |
3220-5 |
NUT-JAM Price: $0.65 |
| 42 |
325-22 |
SCREW-HH This part replaces 325-21. Price: $4.26 |
| 43 |
3-6778 |
AXLE SLINGER Price: $1.98 |
| 44 |
3-6777 |
WASHER Price: $1.98 |
| 46 |
3-6775 |
WASHER Price: $1.21 |
| 47 |
3-0139 |
DISCONTINUED X-REF Price: Call Us |
| 48 |
46-6230 |
DISCONTINUED This part replaces 3-6774. Price: Call Us |
| 49 |
3-6776 |
SPACER Price: $9.65 |
| 50 |
32146-13 |
NUT-HEX Price: $3.49 |
| 51 |
26-1530-01 |
FORK-CASTOR This part replaces 26-1530. Price: $178.41 |
| 52 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 53 |
38-5780 |
SPACER *R Price: $16.56 |
| 54 |
3231-22 |
SCREW-CARR Price: $0.72 |
