| Ref | Part Number | Description |
|---|
| 1 |
132-6203 |
CONTROL KIT Price: $3,452.34 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
132-6204 |
COIL KIT Price: $736.78 |
| 3 |
136-4397 |
CHARGE RELIEF KIT Price: $86.77 |
| 5 |
136-4399 |
SHAFT Price: $425.69 |
| 6 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 7 |
125-5280 |
RING-RETAINING Price: $11.40 |
| 8 |
131-8616 |
RING-RETAINING Price: $16.97 |
| 9 |
127-6214 |
SEAL-LIP Price: $131.03 |
| 10 |
136-4398 |
VALVE PLATE Price: $462.40 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
132-6206 |
O-RING Price: $7.73 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 12 |
125-5288 |
O-RING Price: $34.23 |
| 13 |
131-7388 |
O-RING Price: Call Us |
| 13 |
532172106 |
PANEL ASM, DASH RH Price: $14.99 |
| 14 |
125-5274 |
SCREW Price: $8.89 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
125-5302 |
PLUG Price: $25.48 |
| 16 |
125-5273 |
NUT-SEAL Price: $21.58 |
| 17 |
125-5272 |
SCREW Price: $9.02 |
| 18 |
125-5283 |
GASKET-CONTROL Price: $41.13 |
| 19 |
125-5269 |
RING-LOCKING Price: $4.61 |
| 20 |
125-5266 |
SCREEN Price: $35.26 |
| 21 |
125-5282 |
SCREW Price: $9.84 |
| 22 |
125-5270 |
SCREW Price: $9.02 |
| 23 |
125-5298 |
O-RING Price: $1.68 |
| 24 |
92-1353 |
SHIM KIT Price: $36.78 |
| 25 |
125-5301 |
PLUG Price: $56.91 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 26 |
75-0240 |
O-RING Price: $2.36 |
| 27 |
84-0560 |
O-RING Price: $4.73 |
| 28 |
69-3080 |
PLUG Price: $40.47 |
| 29 |
69-3130 |
PLUG Price: $62.97 |
| 30 |
532192814 |
FENDER.W/CUPHOLDER.ORANGE This part replaces 532191815. Price: $219.99 |
| 30 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 31 |
125-5270 |
SCREW Price: $9.02 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
110-6485 |
PIN-SLOTTED Price: $1.97 |
| 33 |
136-4393 |
VALVE-RELIEF, HIGH PRESSURE Price: $709.20 |
| 34 |
136-4392 |
VALVE-RELIEF, HIGH PRESSURE Price: $709.20 |
| 35 |
132-6205 |
OVERHAUL SEAL KIT Price: $239.18 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 39 |
532407807 |
BRACKET PIVOT This part replaces 532174714. Price: $27.99 |
| 58 |
532151171 |
AIR DUCT This part replaces 532184463. Price: $46.99 |
| 60 |
872140606 |
Bolt - Rd. Hd. Sq. Neckiage 3/8 16 x 3/4 Price: $4.99 |
| 64 |
532174997 |
DASH LOWER Price: $24.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 158 |
532162037 |
BRACKET PARKING BRAKE Price: $3.39 |
| 159 |
532191120 |
CUPHOLDER.RIGHT.GREY This part replaces 532185434. Price: $8.99 |
| 166 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 217 |
532179132 |
CONSOLE FUEL WINDOW GRAY This part replaces 532185436. Price: $7.99 |
| 278 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 280 |
817000616 |
SCREW 3/8-16X1 This part replaces 817060616. Price: $5.99 |
