| Ref | Part Number | Description |
|---|
| 1 |
283-61 |
PIN-YOKE Price: $1.56 |
| 2 |
282-2 |
YOKE Price: $30.04 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
3220-2 |
NUT-JAM Price: $0.50 |
| 4 |
49-5430 |
ROD-CONTROL Price: $75.94 |
| 5 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 6 |
49-6110-01 |
GUARD-ROD, TRANSMISSION This part replaces 49-6110. Price: $65.82 |
| 7 |
10-8140 |
SPRING-LATCH, BRAKE Price: $18.38 |
| 8 |
95-1628 |
DISCONTINUED Price: Call Us |
| 9 |
93-8062 |
DECAL-BRAKE, PARKING Price: $4.95 |
| 10 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 11 |
32141-111 |
NUT-ADJUSTING Price: $6.09 |
| 12 |
83-0640-01 |
PLATE-FOOTREST This part replaces 83-0640. Price: $105.48 |
| 13 |
49-6120 |
PAD-FOOTREST Price: $33.37 |
| 14 |
93-8075 |
DECAL-MOW/LIFT Price: $6.44 |
| 15 |
3274-31 |
SCREW-HSBH This part replaces 3274-68. Price: $0.89 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
321-4 |
SCREW-HH Price: $0.99 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
83-0200-01 |
PLATE-COVER, LH This part replaces 83-0200. Price: $46.92 |
| 18 |
32128-33 |
NUT-HF Price: $0.25 |
| 19 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 20 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 21 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 22 |
95-1629 |
HINGE-LOWER Price: $10.72 |
| 23 |
10-7850 |
LATCH-BRAKE, PARKING Price: $111.12 |
| 24 |
3-1506 |
BUSHING Price: $2.42 |
| 25 |
83-0080 |
SPRING-PIVOT, LIFT Price: $20.57 |
| 26 |
106-6396 |
LIFT-PIVOT V This part replaces 83-0060. Price: $63.16 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 28 |
88-9640-01 |
BRACKET-LIFT PIVOT, LH This part replaces 88-9640. Price: $42.90 |
| 29 |
27-2270 |
ROD-ADJUSTMENT, BRAKE Price: $32.18 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 31 |
10-8100-01 |
STRAP-SHAFT, BRAKE This part replaces 10-8100. Price: $34.17 |
| 32 |
32121-35 |
PIN-ROLL Price: $0.79 |
| 33 |
27-2320 |
BEARING Price: $15.22 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 35 |
3256-38 |
WASHER-FLAT Price: $0.49 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 36 |
106-6395 |
CUTTING CONTROL SHAFT ASM This part replaces 88-9660. Price: $151.92 |
| 37 |
93-7631 |
PAD-FOOT, LIFT Price: $8.10 |
| 38 |
106-6394 |
MOW PEDAL ASM This part replaces 83-0140. Price: $72.96 |
| 39 |
93-7630 |
PAD-FOOT Price: $8.20 |
| 40 |
88-9630-01 |
BRACKET-LIFT PIVOT, RH This part replaces 88-9630. Price: $42.90 |
| 41 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 42 |
49-6200-01 |
LEVER-CUTTING This part replaces 49-6200. Price: $100.17 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
321-11 |
SCREW-HH Price: $0.36 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 45 |
56-7970 |
CLAMP-TUBE Price: $10.02 |
| 46 |
95-5997 |
DECAL Price: $28.82 |
| 47 |
83-2590 |
BOLT-SHOULDER, PIVOT Price: $50.18 |
| 48 |
83-0160 |
SHAFT-BRAKE Price: $111.83 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 49 |
93-7629 |
PAD-FOOT, BRAKE Price: $25.13 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 50 |
69-9760 |
COVERPLATE Price: $5.38 |
| 51 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
321-3 |
SCREW-HH Price: $0.28 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 54 |
76-0410 |
SPRING-COMPRESSION Price: $5.92 |
| 55 |
93-9904 |
ARM-MOW, LOCKOUT Price: $29.06 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 56 |
93-9903 |
PIN-MOW, LOCKOUT Price: $65.65 |
| 57 |
93-9898 |
DECAL-LOCK Price: $5.59 |
| 58 |
93-9901-01 |
BRACKET-LOCKOUT, MOW This part replaces 93-9901. Price: $92.00 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 80 |
532412170 |
STRAP TORQUE.ASM.K46/18"TEX Price: $12.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532401034. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 This part replaces 532197290. Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532195804 |
LINK.CLUTCH.ANIT-ROTAT Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532416863 |
PEDAL.FORWARD.HUSQVARNA.DEALER Price: $32.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 226 |
531170501 |
SERVICE KIT BRACKET This part replaces 532401564. Price: $4.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 284 |
532417693 |
NUT.U-CHNL.1/4-20.550DP.350PNL Price: $3.99 |
