| Ref | Part Number | Description |
|---|
| 1 |
110-4817 |
KIT - AXLE HOUSING This part replaces 95-7538. Price: $657.17 |
| 1 |
198875 |
SPEED SELECTOR ASSEMBLY Price: Call Us |
| 2 |
115-0622 |
SEAL - OIL This part replaces 100-2557. Price: $10.23 |
| 2 |
17501010 |
SCREW 10-24 X .625 Price: Call Us |
| 3 |
104-2378 |
BUSHING Price: $40.73 |
| 3 |
402685X505 |
END PLATE Price: Call Us |
| 4 |
106-1069 |
O-RING This part replaces 104-2372. Price: $5.20 |
| 4 |
17490508 |
SCREW 5/16-18 X .50 Price: Call Us |
| 5 |
104-2373 |
KNUCKLE Price: $58.69 |
| 5 |
57079 |
WASHER Price: Call Us |
| 6 |
104-2374 |
BOLT Price: $6.33 |
| 6 |
405485 |
CONTROL ARM Price: Call Us |
| 7 |
100-3768 |
LH STEERING ARM ASM Price: $207.28 |
| 7 |
198580 |
CLEVIS PIN Price: Call Us |
| 8 |
100-3766 |
RH STEERING ARM ASM Price: $207.28 |
| 8 |
403097X004 |
SHIFTER PLATE Price: Call Us |
| 9 |
402881 |
SHOULDER BOLT Price: Call Us |
| 10 |
403096 |
X004 SHIFTER BRACKET Price: Call Us 403096 X004 |
| 10 |
95-7547 |
SHIM 0.1 Price: $2.53 |
| 10 |
95-7548 |
SHIM 0.2 Price: $3.52 |
| 10 |
95-7549 |
SHIM 0.3 Price: $3.82 |
| 11 |
191730 |
NUT 1/4-20 Price: Call Us |
| 11 |
99-7597 |
PIN-DOWEL Price: $3.74 |
| 12 |
104-2375 |
BOLT Price: $18.54 |
| 12 |
402856 |
X004 CLUTCH PLATE Price: Call Us 402856 X004 |
| 13 |
416717X004 |
CLUTCH BRACKET Price: Call Us |
| 13 |
99-7599 |
BOLT Price: $3.17 |
| 14 |
187101 |
SHIFTER LINK Price: Call Us |
| 14 |
99-7525 |
STUD Price: $7.03 |
| 15 |
700279 |
RETAINER Price: Call Us |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
427542 |
CONTROL SHAFT Price: Call Us |
| 16 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 17 |
402568 |
CLUTCH ROD Price: Call Us |
| 18 |
106-1141 |
STEERING TIE ROD ASM This part replaces 100-3762. Price: $642.02 |
| 18 |
169675 |
RETAINER Price: Call Us |
| 19 |
401732 |
SHIFTER YOKE Price: Call Us |
| 20 |
402310 |
PIVOT ROD Price: Call Us |
| 21 |
12000036 |
RETAINER Price: Call Us |
| 22 |
402878 |
RETURN SPRING Price: Call Us |
| 23 |
751153 |
NUT 5/16-18 Price: Call Us |
| 24 |
408981 |
BEARING Price: Call Us |
| 25 |
73930500 |
NUT 5/16-18 Price: Call Us |
| 26 |
198176X479 |
RUBBER WHEEL PLATE Price: Call Us |
| 27 |
179831 |
RUBBER RING Price: Call Us |
| 28 |
175344 |
BEARING Price: Call Us |
| 29 |
178613 |
WHEEL HUB Price: Call Us |
| 30 |
74760514 |
SCREW 5/16-18-.875 Price: Call Us |
| 31 |
12000012 |
RETAINER RING Price: Call Us |
| 32 |
402187 |
SPROCKET SHAFT Price: Call Us |
| 33 |
401619 |
CHAIN Price: Call Us |
| 34 |
417234 |
SPROCKET WELDMENT Price: Call Us |
| 35 |
401984X479 |
SHIFTER BRACKET Price: Call Us |
| 36 |
180135 |
SPRING Price: Call Us |
| 37 |
402652 |
PLATE PIVOT ROD Price: Call Us |
| 38 |
428288 |
E-RING .375 Price: Call Us |
| 39 |
184471 |
SHOULDER SCREW Price: Call Us |
| 40 |
410877 |
BOTTOM PAN Price: Call Us |
| 41 |
413429X479 |
SPRING BRACKET Price: Call Us |
| 42 |
402689 |
DRIVE PLATE ASSEMBLY Price: Call Us |
| 43 |
414557 |
IDLER SPRING Price: Call Us |
| 44 |
178828 |
IDLER SPRING Price: Call Us |
| 45 |
402504 |
PULLEY SHAFT Price: Call Us |
| 46 |
401820 |
DRIVE PLATE Price: Call Us |
| 47 |
198791 |
BEARING Price: Call Us |
| 48 |
402393 |
PULLEY HALF Price: Call Us |
| 49 |
17541008 |
SCREW 10-24 X .50 Price: Call Us |
| 50 |
402511 |
SPACER BEARING Price: Call Us |
| 51 |
418894X479 |
SWING PLATE Price: Call Us |
| 52 |
132010 |
NUT 3/8-16 Price: Call Us |
