| Ref | Part Number | Description |
|---|
| 1 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 2 |
26-1840 |
PULLEY-IDLER Price: $42.68 |
| 3 |
100-6578 |
DECAL-DANGER Price: $13.28 |
| 4 |
26-1760 |
PULLEY AND HUB ASM Price: $214.86 |
| 5 |
26-1860 |
SPACER-IDLER PULLEY Price: $4.75 |
| 6 |
32128-21 |
NUT-HF Price: $0.39 |
| 7 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 8 |
26-1870-03 |
MOUNT-IDLER Price: $74.13 |
| 9 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 10 |
26-1850 |
STUD-IDLER Price: $32.97 |
| 11 |
21-0890 |
V-BELT Price: $32.90 |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 13 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 14 |
84-2060 |
PULLEY AND HUB ASM Price: $276.94 |
| 15 |
253-138 |
SEAL-OIL Price: $10.33 |
| 16 |
49-8320 |
BEARING ASM Price: $104.42 |
| 18 |
106-6753 |
DECAL-DANGER, CE Price: $8.07 |
| 19 |
93-7817 |
DECAL-TORQUE, BLADE BOLT Price: $25.65 |
| 20 |
84-2020 |
HOUSING-SPINDLE Price: $297.31 |
| 21 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 22 |
138-6391 |
SHAFT-SPINDLE This part replaces 84-2070. Price: $328.69 |
| 23 |
29-5530-03 |
BLADE-STANDARD, 25 INCH, LH Price: $40.07 |
| 24 |
26-1990 |
WASHER-BELLEVILLE Price: $16.49 |
| 25 |
26-1820 |
CAPSCREW Price: $37.35 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 28 |
107-2908 |
DECAL-DANGER, COMBINATION Price: $10.77 |
| 29 |
26-1880 |
SPACER-IDLER MOUNT Price: $13.91 |
| 30 |
105-7844 |
DECAL-WARNING Price: $8.57 |
| 31 |
323-12 |
SCREW-HH Price: $1.14 |
| 32 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 33 |
84-5370 |
SPINDLE Price: $259.86 |
| 34 |
31-0750 |
ROLLER-FRONT Price: $42.15 |
| 35 |
3296-38 |
NUT-LOCK, NI This part replaces 32-9610. Price: $1.89 |
| 36 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 37 |
57-0280 |
DECAL Price: $12.24 |
| 38 |
84-2090 |
SPACER-SPINDLE, RH Price: $32.37 |
| 39 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
253-154 |
SEAL-OIL Price: $5.48 |
| 41 |
302-52 |
FITTING-GREASE Price: $1.49 |
| 42 |
84-2080 |
HOUSING-SPINDLE, CENTER Price: $270.66 |
