| Ref | Part Number | Description |
|---|
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
195223 |
Shaft Asm., Lift Price: Call Us |
| 2 |
63-8410 |
WASHER Price: $1.76 |
| 3 |
110-6384-03 |
BRACKET-GEARBOX, LH Price: $61.81 |
| 3 |
195231 |
Lever Asm., Lift Rh Price: Call Us |
| 4 |
63-9750 |
MOUNT Price: $18.92 |
| 5 |
3231-26 |
SCREW-CARR Price: $0.86 |
| 6 |
130-8659 |
GEARBOX ASM This part replaces 110-6386-03. Price: $843.83 |
| 7 |
196492X421 |
Grip, Lever Price: Call Us |
| 8 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 9 |
110-6385-03 |
BRACKET-GEARBOX, RH Price: $61.81 |
| 10 |
196314 |
Spring Torsion Price: Call Us |
| 10 |
323-4 |
SCREW-HH Price: $1.02 |
| 11 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 17 |
112-9559 |
GROMMET Price: $5.38 |
| 19 |
93-6687 |
DECAL-NO STEP Price: $14.45 |
| 20 |
112-1450-03 |
COVER-DECK, LH Price: $121.56 |
| 21 |
112-1451-03 |
COVER-DECK, RH Price: $66.36 |
| 22 |
93-6697 |
DECAL-LUBE Price: $11.38 |
| 23 |
106-2240 |
KNOB Price: $12.99 |
| 24 |
110-3510 |
NUT-RETAINER Price: $5.77 |
| 87 |
194209 |
Pin Cotter 7/16 Bow Tie Lock Price: Call Us |
| 88 |
195303 |
Spring Lift Assist Price: Call Us |
| 89 |
19191912 |
Washer Clear Zinc Price: Call Us |
| 90 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 91 |
403407 |
Link Lift Susp Mower Rear Price: Call Us |
| 97 |
17060612 |
Screw 3/8-16 x .75 Smgml Tap/R.Z Price: Call Us |
