| Ref | Part Number | Description |
|---|
| 1 |
67-7160 |
BLOCK-FUSE Price: $18.75 |
| 2 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 2 |
532007070 |
KEY 1/4 X 2.5 Price: $4.99 |
| 3 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 4 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 5 |
322-13 |
SCREW-HH Price: $2.73 |
| 6 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 7 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
531149201 |
SERVICE KIT HUB.ASM HUB.ASM.WH This part replaces 532199837. Price: $39.99 |
| 8 |
283-49 |
PIN-CLEVIS Price: $1.02 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 9 |
92-5759 |
PLATE-SEAT Price: $194.60 |
| 10 |
66-2800-03 |
ROD-SUPPORT ASM This part replaces 66-2800. Price: $65.99 |
| 11 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 12 |
321-4 |
SCREW-HH Price: $0.99 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
66-2630 |
LATCH-SEAT Price: $18.77 |
| 15 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
52-1321 |
DECAL-FUEL, DIESEL Price: $9.16 |
| 16 |
93-6680 |
DECAL-DIESEL Price: $19.31 |
| 17 |
532401072 |
SPRING.BRAKE.K46 Price: $6.99 |
| 18 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 19 |
110-4105 |
HOSE-FUEL This part replaces 63-7620. Price: $11.71 |
| 20 |
27-7180 |
CAP Price: $70.51 |
| 21 |
94-3309 |
DISCONTINUED Price: Call Us |
| 22 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 23 |
115-8155 |
DECAL-WARNING This part replaces 93-7275. Price: $5.90 |
| 23 |
83-9150 |
DECAL-FLUID, STARTING Price: $20.09 |
| 25 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 26 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 28 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 29 |
532407245 |
ROD.BRAKE.K66 Price: $14.99 |
| 29 |
66-2451-03 |
BRACKET-AIR CLEANER This part replaces 66-2451. Price: $30.72 |
| 30 |
3258-19 |
SCREW Price: $0.42 |
| 31 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 32 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 33 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 33 |
812000053 |
E RING HYT Price: $3.99 |
| 34 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 35 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 35 |
583864502 |
Rods This part replaces 532435486. Price: $6.99 |
| 36 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 37 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 38 |
321-8 |
SCREW-HH Price: $0.34 |
| 39 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 40 |
53-8150 |
PUMP-FUEL Price: $680.19 |
| 41 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 42 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
66-2590 |
DISCONTINUED Price: Call Us |
| 44 |
37-9590 |
DISCONTINUED Price: Call Us |
| 45 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 46 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 47 |
63-7590 |
RELAY Price: $78.15 |
| 48 |
67-1710 |
DECAL-WARNING Price: $7.83 |
| 49 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 50 |
66-8800 |
RELAY Price: $87.56 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
92-7892 |
SEAT SWITCH BRKT. ASM Price: $46.04 |
| 52 |
2412-74 |
R-CLAMP Price: $2.37 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
37-2690 |
CAPACITOR Price: $155.98 |
| 54 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 55 |
92-8877 |
SEAT FRAME ASM This part replaces 92-7894. Price: $257.82 |
| 56 |
532125907 |
BELT Price: $34.99 |
| 56 |
66-8750 |
DECAL - THROTTLE LIFT Price: $18.86 |
| 56 |
93-7833 |
DECAL-THROTTLE AND LIFT CONTROL Price: $12.96 |
| 57 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 58 |
237-30 |
O-RING Price: $2.50 |
| 59 |
43-8610 |
GUIDE Price: $23.35 |
| 60 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 61 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 62 |
237-7 |
O-RING Price: $8.82 |
| 63 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 64 |
218-461 |
NUT-HH Price: $2.50 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 65 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 66 |
28-8070 |
LANYARD Price: $13.85 |
| 68 |
67-1690 |
FITTING-SPECIAL Price: $8.57 |
| 69 |
321-6 |
SCREW-HH Price: $0.25 |
| 69 |
532123800 |
WASHER Price: $3.99 |
| 70 |
532439661 |
CONSOLE.ASM.RH.GT.FC.HUSQ Price: $79.99 |
| 71 |
2412-107 |
CLAMP-R Price: $2.65 |
| 72 |
322-3 |
SCREW-HH Price: $0.79 |
| 73 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 73 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 74 |
66-2450-03 |
DISCONTINUED This part replaces 66-2450. Price: Call Us |
| 75 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 76 |
32128-33 |
NUT-HF Price: $0.25 |
| 77 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 78 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 79 |
32148-9 |
NUT-CLINCH Price: $2.65 |
| 80 |
43-2570 |
GASKET-PUMP Price: $15.12 |
| 80 |
589333402 |
STRAP.PNT.TORQUE.K66.EDIP This part replaces 532407182. Price: $22.99 |
| 81 |
43-2550 |
FILTER-PUMP Price: $23.30 |
| 82 |
43-2560 |
GASKET-PUMP Price: $23.14 |
| 83 |
43-2580 |
MAGNET-PUMP Price: $12.24 |
| 84 |
322-14 |
SCREW-HH Price: $1.01 |
| 85 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 86 |
80-3330 |
GASKET Price: $18.48 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415744 |
ROD.SPRING.BYPASS.K66.GT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
532407246 |
ROD.PEDAL.CONTROL Price: $37.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532197357 |
SPACER.AXLE.HG.TEX Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532441455. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532199769 |
BRKT.ANIT-ROTATION.CLUTCH Price: $6.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
532407311 |
KEEPER.BELT.TRANSAXLE.K66 Price: $11.99 |
