| Ref | Part Number | Description |
|---|
| 1 |
115-8092 |
SWASHPLATE Price: $863.05 |
| 1 |
532170805 |
CONTROL.THROTTLE.LT/YT Price: $27.99 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 2 |
75-0400 |
PLATE-THRUST Price: $41.27 |
| 3 |
110-6483 |
BEARING KIT Price: $125.81 |
| 4 |
110-6471 |
SEAL-LIP Price: $50.69 |
| 4 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 5 |
95-4400 |
WASHER-BACKUP Price: $7.74 |
| 6 |
69-3200 |
RING-RETAINING Price: $20.29 |
| 7 |
110-6484 |
SHAFT-AUXILIARY Price: $714.38 |
| 8 |
110-6472 |
CYLINDER BLOCK KIT ASM Price: $1,735.97 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
110-6473 |
PLATE-VALVE (CLOCKWISE) Price: $593.29 |
| 10 |
110-6485 |
PIN-SLOTTED Price: $1.97 |
| 11 |
110-6486 |
PLUG-RELIEF, CHARGE Price: $67.11 |
| 12 |
110-6480 |
COUPLING Price: $478.20 |
| 13 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 13 |
92-1353 |
SHIM KIT Price: $36.78 |
| 14 |
110-6474 |
SPRING Price: $31.79 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
110-6475 |
POPPET Price: $36.37 |
| 16 |
115-8087 |
CAP-END Price: $1,692.55 |
| 17 |
110-6476 |
GASKET-CAP, END Price: $31.07 |
| 18 |
75-0500 |
BEARING-NEEDLE Price: $83.78 |
| 19 |
110-6489 |
SCREW Price: $13.10 |
| 20 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 21 |
107-4364 |
BYPASS VALVE ASM Price: $166.69 |
| 22 |
110-6491 |
SPRING Price: $26.02 |
| 23 |
110-6492 |
SPOOL-LOOP, FLUSH Price: $103.46 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
110-6493 |
PIVOT-RETURN, NEUTRAL Price: $265.40 |
| 25 |
69-3170 |
RING-RETAINING Price: $11.40 |
| 26 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 27 |
115-8085 |
SPRING-NEUTRAL RETURN Price: $71.60 |
| 28 |
110-6496 |
NUT-SEAL Price: $10.99 |
| 29 |
110-6497 |
NEUTRAL RETURN ARM ASM Price: $301.72 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
69-3130 |
PLUG Price: $62.97 |
| 31 |
112-0158 |
PIN Price: Call Us |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
110-6477 |
VALVE-RELIEF Price: $438.26 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 36 |
110-6499 |
TRUNNION COVER ASM Price: $262.88 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 38 |
84-0430 |
O-RING Price: $6.94 |
| 39 |
112-0150 |
SCREW Price: $1.90 |
| 40 |
84-0440 |
COVER-TRUNNION Price: $235.07 |
| 41 |
112-0151 |
SCREW Price: $4.27 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 117 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
