| Ref | Part Number | Description |
|---|
| 1 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 1 |
539105232 |
DECAL, ANTI SCALP Price: $2.99 |
| 1 |
MA-30A26-00500 |
GEAR,OIL PUMP Not Available Price: |
| 2 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 2 |
539100344 |
DECAL, DANGER Price: $2.42 |
| 2 |
MA-30A26-00200 |
BEARING.NTN 6205LU Not Available Price: |
| 3 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 3 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 3 |
MA-30H05-00102 |
CAMSHAFT Not Available Price: |
| 4 |
115-3276 |
KIT-SERVICE, CASTOR FORK This part replaces 99-1492-01. Price: $530.51 |
| 4 |
539105012 |
DECAL, BELT ROUTING Price: $1.55 |
| 4 |
MA-MM406722 |
GEAR,CAMSHAFT Not Available Price: |
| 5 |
539104790 |
DECAL, HUSQVARNA 17.5" Price: $12.99 |
| 5 |
70-8370 |
BOLT Price: $73.52 |
| 5 |
MA-MF476215 |
KEY Not Available Price: |
| 6 |
539102670 |
DECAL, FUEL VALVE Price: $2.99 |
| 6 |
72-9710 |
HUB-TIRE Price: $288.21 |
| 6 |
MA-MD000425 |
WASHER Not Available Price: |
| 7 |
114-4665 |
TIRE ASM This part replaces 99-8186. Price: $226.02 |
| 7 |
539105010 |
DECAL, CONSOLE Price: $7.11 |
| 7 |
MA-MM40666101 |
IDLER GEAR Not Available This part replaces MA-MM406661. Price: |
| 8 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 8 |
539100128 |
DECAL, EXHAUST Price: $1.99 |
| 8 |
MA-MM431415 |
CAMSHAFT, INJ. PUMP Not Available Price: |
| 9 |
3296-67 |
NUT-LOCK, NI Price: $5.05 |
| 9 |
539104789 |
DECAL, CROWN H Price: $3.10 |
| 9 |
MA-MD703856 |
BEARING NSK62/128 Not Available Price: |
| 10 |
106-6774 |
JOINT-BALL This part replaces 92-5838. Price: $79.04 |
| 10 |
539104787 |
DECAL, HUSQVARNA LOGO 9.25" Price: $10.99 |
| 10 |
MA-30H65-08100 |
GEAR-INJ P Not Available Price: |
| 11 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 11 |
539102669 |
DECAL, BATTERY Price: $1.65 |
| 11 |
MA-MF241251 |
BOLT Not Available Price: |
| 12 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 12 |
596024201 |
DECALS.WARN.CA.SPKARREST/PROP This part replaces 539101881. Price: $1.99 |
| 12 |
MA-MF476018 |
KEY Not Available Price: |
| 13 |
132-3778 |
CYLINDER-STEERING This part replaces 93-2122. Price: $786.47 |
| 13 |
589283001 |
DECAL.ZTR.MOTCONTRL.SYMBOL.HUS This part replaces 539103333. Price: $3.99 |
| 13 |
MA-MD008761 |
RETAINER Not Available Price: |
| 14 |
539103328 |
DECAL,THROWN OBJECT Price: $4.99 |
| 14 |
93-2270 |
HYD HOSE ASM Price: $91.88 |
| 14 |
MA-MD008760 |
LOCK-VALVE SPRING Not Available Price: |
| 15 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 15 |
539103331 |
DECAL, WARNING Price: $3.26 |
| 15 |
MA-MM41306001 |
VALVE SEAL Not Available This part replaces MA-MM413060. Price: |
| 16 |
117-9471 |
KIT-SERVICE,GR3250-D STEERING This part replaces 93-2269. Price: $105.67 |
| 16 |
539104898 |
DECAL, HEIGHT Price: $5.99 |
| 17 |
3220-6 |
NUT-JAM Price: $1.25 |
| 17 |
539104899 |
DECAL, HEIGHT Price: $4.99 |
| 17 |
MA-31A05-00300 |
TAPPET Not Available This part replaces MA-MM402737. Price: |
| 18 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 18 |
539105011 |
DECAL, SERVICE Price: $3.99 |
| 18 |
MA-30H04-04700 |
INTAKE VALVE Not Available This part replaces MA-MM433495. Price: |
| 19 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 19 |
539102892 |
DECAL, NO STEP Price: $0.64 |
| 19 |
MA-30H04-04600 |
EXHAUST VALVE Not Available This part replaces MA-MM433496. Price: |
| 20 |
539105071 |
DECAL, NASCAR Price: $1.91 |
| 20 |
70-8490 |
SPACER-SPINDLE, REAR Price: $24.99 |
| 20 |
MA-K7331230 |
ROD Not Available Price: |
| 21 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 21 |
539105053 |
DECAL, ZTH5223L This part replaces 539105322. Price: $12.34 |
| 21 |
539105056 |
DECAL, ZTH6125 This part replaces 539105324. Price: $14.99 |
| 21 |
539105321 |
DECAL, 5223 Price: $2.14 |
| 21 |
539105323 |
DECAL 5225 Price: $21.66 |
| 21 |
539105548 |
DECAL Price: $11.81 |
| 21 |
MA-MD000963 |
SPRING Not Available Price: |
| 22 |
99-1493 |
DECAL Price: $34.25 |
| 22 |
MA-MM406732 |
ARM ROCKER Not Available Price: |
| 23 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 23 |
MA-MM406745 |
WASHER Not Available Price: |
| 24 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 24 |
MA-MM435527 |
SHAFT ASSEMBLY,ROCKER Not Available Price: |
| 25 |
99-1485-01 |
PLATE-ADAPTER, MOTOR Price: $41.54 |
| 25 |
MA-MM413043 |
BRACKET Not Available Price: |
| 26 |
99-1486-01 |
PLATE-ADAPTER Price: $35.80 |
| 26 |
MA-K7231220 |
SCREW Not Available Price: |
| 27 |
325-6 |
SCREW-HH Price: $1.42 |
| 27 |
MA-MF241225 |
BOLT Not Available Price: |
| 28 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 28 |
MA-A3030110003 |
NUT Not Available This part replaces MA-MF430726. Price: |
| 29 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
MA-07400001900 |
SNAP RING Not Available Price: |
| 31 |
MA-MF244891 |
BOLT Not Available Price: |
| 32 |
MA-MF241293 |
BOLT Not Available Price: |
