| Ref | Part Number | Description |
|---|
| 1 |
38-9370 |
RH CASTOR ARM ASM Price: $946.82 |
| 1 |
486499 |
Seat, SZL Price: Call Us |
| 2 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 2 |
483559 |
Cable, Seat Stop Price: Call Us |
| 3 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 3 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 4 |
26-1890 |
DISCONTINUED Price: Call Us |
| 5 |
3217-7 |
NUT-HEX Price: $0.28 |
| 5 |
463384 |
Seat-Plate W/Decal Price: Call Us |
| 6 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 7 |
39-3330-01 |
PLATE-CLAMP, CASTOR ARM This part replaces 39-3330. Price: $36.10 |
| 8 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 8 |
325-13 |
SCREW-HH Price: $3.57 |
| 9 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 9 |
39-3340-01 |
BRACKET-ARM CLAMP This part replaces 39-3340. Price: $101.90 |
| 10 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 10 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 11 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 11 |
8-0909 |
DISCONTINUED Price: Call Us |
| 12 |
483372 |
Spring, Seat Price: Call Us |
| 12 |
93-9838-03 |
SHROUD-SHAFT, DRIVE This part replaces 26-2250. Price: $56.70 |
| 13 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 13 |
427341 |
Seat Stop Price: Call Us |
| 14 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 14 |
3-1365 |
CHAIN This part replaces 21-3160. Price: $72.97 |
| 15 |
04001-18 |
Bolt, Hex Head, 3/8-16 x 3/4" Price: Call Us |
| 15 |
5-2942 |
SHACKLE Price: $16.99 |
| 16 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 16 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 17 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 17 |
427961 |
Plate, Anti-Rotation Price: Call Us |
| 18 |
26-7970 |
CAUTION DECAL (BLADE) Price: $14.83 |
| 18 |
428187 |
Plate, Spacer Price: Call Us |
| 19 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 19 |
26-1900 |
DISCONTINUED Price: Call Us |
| 20 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 20 |
428131 |
Skid Plate, SZL-36 Price: Call Us |
| 21 |
26-1580 |
SPACER 1/2 IN Price: $9.91 |
| 21 |
426727 |
Bracket, Switch Price: Call Us |
| 22 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 22 |
94-1291 |
BUSHING This part replaces 28-9290. Price: $10.99 |
| 23 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 23 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 24 |
04132-01 |
Threaded insert, Hex Head (Pressed) Price: Call Us |
| 24 |
38-9420 |
LH CASTOR ARM ASM Price: $993.47 |
| 25 |
04132-01 |
Threaded insert, Hex Head (Pressed) Price: Call Us |
| 25 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 26 |
481284 |
Bumper, Rubber 5/16-18 x 5/8" Price: Call Us |
| 26 |
99-5690 |
CASTOR FORK ASM This part replaces 26-1560. Price: $183.50 |
| 27 |
21-3870 |
AXLE ASM Price: $14.07 |
| 27 |
428183 |
Battery Hold Down Price: Call Us |
| 28 |
428186 |
Battery Box Price: Call Us |
| 28 |
46-8970 |
WASHER Price: $5.29 |
| 29 |
46-9030 |
BEARING RETAINER Price: $4.91 |
| 29 |
463349 |
Frame Assembly, SZL-36H & SZL42H Price: Call Us |
| 30 |
21-1030 |
SPANNER BUSHING Price: $17.87 |
| 31 |
21-3860 |
WHEEL Price: $85.23 |
| 31 |
485243 |
Bearing Price: Call Us |
| 32 |
21-3850 |
ROLLER BRG W/46-8960 Price: $15.21 |
| 32 |
43974 |
Spacer, Wheel Bearings Price: Call Us |
| 33 |
32153-7 |
NUT-LOCK Price: $0.75 |
| 33 |
483417 |
Tire, 11 x 4-5.00 2-Ply Price: Call Us |
| 34 |
3233-1 |
SCREW-CARR Price: $1.42 |
| 35 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 35 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 36 |
04001-80 |
Bolt, Hex Head 1/2-13 x 6-1/2" (52V) Price: Call Us |
| 36 |
3217-9 |
NUT-HH Price: $0.37 |
| 37 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 38 |
3217-8 |
NUT-HEX Price: $1.34 |
| 38 |
424636 |
Spacer, Yoke Price: Call Us |
| 39 |
325-22 |
SCREW-HH This part replaces 325-21. Price: $4.26 |
| 39 |
483466 |
Bearing Price: Call Us |
| 40 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25" x .1875 Price: Call Us |
| 40 |
3-6778 |
AXLE SLINGER Price: $1.98 |
| 41 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 41 |
3-6777 |
WASHER Price: $1.98 |
| 42 |
04040-11 |
Flatwasher, 7/16" (.500 x 1.25 x .083") Price: Call Us |
| 43 |
3-6775 |
WASHER Price: $1.21 |
| 43 |
43736 |
Spacer, Caster Bearing Price: Call Us |
| 44 |
428141 |
Plate, Backing Price: Call Us |
| 45 |
427875 |
Plate, Decal Price: Call Us |
| 45 |
46-6230 |
DISCONTINUED Price: Call Us |
| 46 |
3-6776 |
SPACER Price: $9.65 |
| 46 |
427868 |
Bumper. Front Price: Call Us |
| 47 |
04090-03 |
Rivot, 3/16 x .402 POP Price: Call Us |
| 47 |
32153-5 |
NUT-HEX Price: $1.59 |
| 48 |
26-1530-01 |
FORK-CASTOR This part replaces 26-1530. Price: $178.41 |
| 49 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 453060 |
Yoke |
Weldment, Caster Price: Call Us 453060 |
