| Ref | Part Number | Description |
|---|
| 1 |
93-5645 |
CENTER SHROUD ASM This part replaces 93-5082. Price: $2,188.91 |
| 2 |
95-6135 |
ROPS ASM-GM3000 This part replaces 93-5044. Price: $1,067.55 |
| 3 |
93-5253 |
STRIP-FOAM, HOOD Price: $21.16 |
| 4 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 5 |
110-4109 |
HOSE-FUEL This part replaces 93-5482. Price: $11.24 |
| 6 |
109-0308 |
HOSE-FUEL This part replaces 93-5484. Price: $10.99 |
| 7 |
93-5083 |
HOSE-CLEANER, AIR Price: $167.33 |
| 8 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 9 |
93-5111 |
CLEANER-AIR Price: $474.66 |
| 10 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 11 |
93-5427 |
SPACER-INTAKE Price: $5.82 |
| 12 |
93-5084 |
HOSE-CLEANER, AIR Price: $83.18 |
| 13 |
93-5420 |
SCREW-HH Price: $1.63 |
| 14 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 15 |
93-5157-03 |
BAR-ROPS ASM This part replaces 93-5157. Price: $133.96 |
| 16 |
33004-00 |
NUT-HF Price: $0.34 |
| 17 |
94-8099 |
DECAL This part replaces 94-3395. Price: $16.38 |
| 18 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 19 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 20 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 21 |
93-5638 |
COVER-TUBE Price: $18.82 |
| 22 |
33113-020 |
SCREW-HH Price: $0.26 |
| 501465301 |
501465301 |
Price: $7.25 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468401 |
501468401 |
SPRING Price: $6.99 |
| 501468501 |
501468501 |
BALL Price: $6.99 |
| 501468601 |
507430749 |
SHUTTER-CHOKE This part replaces 501468601. Price: $2.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501469601 |
501469502 |
This part replaces 501469601. Price: $5.10 |
| 501469701 |
530035124 |
CHECK VALVE SCREEN This part replaces 501469701. Price: $1.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501666201 |
501666201 |
COVER, PUMP SIDE Price: $5.99 |
| 501666701 |
501666701 |
THROTTLE STOP Price: $0.83 |
| 501666801 |
503563401 |
INLET NEEDLE This part replaces 501666801. Price: $14.99 |
| 501666901 |
501666901 |
GASKET, PUMP SIDE Price: $14.99 |
| 501667001 |
501667001 |
GASKET, METERING SIDE Price: $6.99 |
| 501667201 |
502254701 |
PUMP DIAPHRAGM This part replaces 501667201. Price: $19.99 |
| 501667301 |
501667301 |
METERING DIAPHRAGM Price: $64.99 |
| 501667601 |
501667601 |
Screw Price: $1.18 |
| 501667701 |
501667701 |
SPRING Price: $7.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 501668301 |
501668301 |
LEVER Price: $14.99 |
| 501668401 |
501668401 |
REPAIR KIT DIAPHRAGM SET Price: $17.99 |
| 501795901 |
501795901 |
SPRING Price: $9.99 |
| 501796201 |
501796201 |
Price: $8.65 |
| 501838501 |
501838501 |
Price: $7.42 |
| 501838601 |
501838601 |
Price: $2.17 |
| 501875801 |
501875801 |
Throttle Flap Price: $2.42 |
| 501876401 |
501876401 |
NEEDLE IDLE Price: $2.41 |
| 503081801 |
503081801 |
Washer Price: $7.50 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503173201 |
503281019 |
CARBURETOR CPL HDA-98 WALBRO This part replaces 503173201. Price: $199.99 |
| 503176301 |
503176301 |
COVER METERING DIAPHR. Price: $4.99 |
| 503176501 |
503176501 |
Price: Call Us |
| 503176601 |
503592750 |
REPAIR KIT CARBURETOR This part replaces 503176601. Price: $2.99 |
| 503177101 |
503177101 |
Needle High Speed Price: $2.12 |
| 504100010 |
530035225 |
CUP PLUG This part replaces 504100010. Price: $2.99 |
| 504100011 |
503574201 |
WELCH PLUG This part replaces 504100011. Price: $6.99 |
| 504140008 |
504140008 |
RING SHAFT RETAINER Price: $1.02 |
| 504210048 |
504210048 |
THROTTLE SPRING Price: $0.53 |
| 504860408 |
537158201 |
LEVER This part replaces 504860408. Price: $3.99 |
| 505520115 |
505520115 |
Price: Call Us |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
