| Ref | Part Number | Description |
|---|
| 1 |
119-3486 |
RH HANDLE ASM Price: $48.21 |
| 2 |
119-3485 |
LH HANDLE ASM Price: $48.21 |
| 3 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
120-7950 |
SCREW-SHOULDER This part replaces 112-4004. Price: $1.79 |
| 6 |
119-3470 |
ACTUATOR ARM ASM Price: $17.50 |
| 7 |
110-6810 |
STUD-DAMPER Price: $3.50 |
| 8 |
131-4132 |
DAMPER This part replaces 103-2913. Price: $43.77 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
119-8925 |
WASHER-BELLEVILLE Price: $0.80 |
| 15 |
117-1240 |
WASHER Price: $1.27 |
| 16 |
119-8832 |
CONTROL-SPEED Price: $50.17 |
| 17 |
121-1753 |
PIN-ROD, HYDRO This part replaces 119-3303. Price: $3.52 |
| 19 |
117-1198 |
BOLT-PIVOT Price: $2.01 |
| 20 |
125-5473-03 |
CONTROL BOX ASM This part replaces 119-3386-03. Price: $143.51 |
| 21 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 22 |
133-9299-05 |
ARM-CONTROL This part replaces 115-5098-05. Price: $32.13 |
| 23 |
120-2273 |
WASHER-NYLON Price: $1.54 |
| 24 |
115-9604 |
ECCENTRIC Price: $1.58 |
| 25 |
119-3301 |
BOLT-PIVOT, ECCENTRIC Price: $1.27 |
| 26 |
115-5099 |
BOLT-PIVOT Price: $2.32 |
| 27 |
119-8876 |
SPRING-RETURN Price: $1.57 |
| 28 |
138-7217 |
ROD-HYDRO This part replaces 117-5388. Price: $8.29 |
| 29 |
138-7218 |
MOUNT-ROD, HYDRO This part replaces 119-8842. Price: $7.95 |
| 30 |
119-8952 |
WASHER Price: $0.77 |
| 31 |
321-3 |
SCREW-HH Price: $0.28 |
| 32 |
121-3017 |
BRAKE CONTROL MODULE ASM This part replaces 115-9660. Price: $121.78 |
| 33 |
117-5385 |
RETAINER Price: $0.81 |
| 34 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 35 |
121-2974 |
ROD-BRAKE, RH This part replaces 119-8816. Price: $7.72 |
| 36 |
121-2975 |
ROD-BRAKE, LH This part replaces 119-8817. Price: $7.72 |
| 37 |
117-1169 |
SPRING-COMPRESSION Price: $1.57 |
| 38 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 39 |
32144-36 |
SCREW-PPH Price: $0.99 |
| 40 |
1-603807 |
SPRING-RETURN, NEUTRAL Price: $3.29 |
| 41 |
119-8859 |
COVER-BRAKE Price: $4.80 |
| 42 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 43 |
93-6079 |
SPACER-NYLON Price: $0.25 |
| 44 |
132-9368 |
KNOB-RH This part replaces 119-8935. Price: $1.63 |
| 45 |
132-9369 |
KNOB-LH This part replaces 119-8936. Price: $1.63 |
| 46 |
94-4496 |
SCREW-PPH Price: $0.89 |
| 47 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 48 |
130-0780 |
DECAL-SPEED CONTROL This part replaces 119-8874. Price: $4.18 |
| 49 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
