| Ref | Part Number | Description |
|---|
| 1 |
144-4153 |
RESERVOIR-HYDRAULIC This part replaces 120-9077. Price: $784.00 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
323-20 |
SCREW-HH Price: $1.28 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 3 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 4 |
121-1456 |
SPACER-THIN Price: $5.19 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
115-9793 |
BREATHER Price: $53.38 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
136-8531 |
GROMMET This part replaces 104-0790. Price: $3.62 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
114-0002 |
PIPE-STAND Price: $70.85 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
874781044 |
Bolt, Hex 5/8 -11 x 2 - 3/4 Gr. 5 Price: $3.99 |
| 10 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 11 |
237-101 |
O-RING Price: $2.80 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 12 |
112-6365 |
DIPSTICK Price: $73.81 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
322-7 |
SCREW-HH Price: $0.89 |
| 15 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 16 |
532145103 |
SHAFT ASM, STEERING Price: $99.99 |
| 17 |
121-1533 |
SPACER-THICK Price: $9.82 |
| 18 |
115-7721 |
NUT-CLIP, U Price: $0.81 |
| 18 |
532175572 |
DRAGLINK, BALL JOINT (3SPG1401 Price: $64.99 |
| 19 |
121-1557-0P |
MOUNT-TANK This part replaces 121-1557-03. Price: $18.23 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 21 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 21 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 23 |
353-508 |
PLUG-HH Price: $7.96 |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 24 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 25 |
120-8810 |
HOSE-STRAINER Price: $38.16 |
| 25 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 26 |
2412-36 |
CLAMP-HOSE This part replaces 115-5436. Price: $1.28 |
| 26 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 27 |
114-4920 |
HOSE Price: $6.72 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 28 |
121-1521 |
HOSE Price: $15.83 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
531165701 |
SERVICE KIT GEAR.ASM.SECT This part replaces 532138059. Price: $49.99 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE This part replaces 532137156. Price: $59.99 |
| 37 |
873360600 |
NUT Price: $4.99 |
| 38 |
532121160 |
JOINT.RH This part replaces 532109850. Price: $19.99 |
| 39 |
873700600 |
NUT Price: $2.99 |
| 40 |
532109851 |
JOINT.LH Price: $27.99 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 44 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 45 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Gauge Price: $2.99 |
