| Ref | Part Number | Description |
|---|
| 0 |
640262A |
CARBURETOR This part replaces 640069. Price: $78.00 |
| 1 |
115-6694 |
YOKE-LIFT Price: $77.72 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
110-8110 |
SPACER Price: $13.38 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
110-8114 |
WASHER Price: $4.14 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 4 |
66-7230 |
SPRING-COMPRESSION Price: $9.25 |
| 5 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
3211-12 |
SCREW-HH Price: $1.70 |
| 6 |
640070 |
SHUTTER Price: $1.25 |
| 7 |
3220-3 |
NUT-HJ Price: $0.28 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
532176689 |
BOX.BATTERY.FENDER Price: $7.99 |
| 8 |
92-7008 |
END-ROD, FEMALE Price: $49.99 |
| 9 |
110-8108 |
ROD-LINK Price: $24.52 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
640027 |
FUEL JET Price: $2.60 |
| 20A |
640053 |
CAP Price: $0.81 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $29.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 24 |
532421297 |
CABLE.GROUND.REAR.BTRY.8GA.44" Price: $14.99 |
| 25 |
532421299 |
CABLE.STARTER.6GA.11"RED Price: $11.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
532421298 |
CABLE GROUND 6 GA. 12" BLACK Price: $9.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 35 |
36045A |
PRIMER Price: $4.99 |
| 36 |
632735 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 40 |
532421251 |
HARNESS.LT.CABLE.HL.AM.HM This part replaces 532197428. Price: $119.99 |
| 40 |
640030 |
NUT Price: $5.16 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 871110408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
