| Ref | Part Number | Description |
|---|
| 1 |
29-5670-01 |
TRACTION PEDAL This part replaces 29-5670. Price: $71.84 |
| 1 |
530035017 |
Pump Cover Screw Price: $0.99 |
| 2 |
28-5130 |
TRACTION PEDAL PAD Price: $33.21 |
| 2 |
530035191 |
Pump Cover Ass'y. (Inc.4) Price: $3.99 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 3 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 4 |
29-5630 |
DISCONTINUED Price: Call Us |
| 4 |
530035156 |
Idle Adjustment Screw Price: $1.99 |
| 5 |
70-9830 |
SHAFT - TRACT. PEDAL This part replaces 29-5640. Price: $21.93 |
| 6 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 6 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 7 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 7 |
530035133 |
Throttle Valve Price: $3.33 |
| 8 |
5-7570 |
WASHER-FLAT Price: $6.19 |
| 8 |
530035007 |
Throttle Shaft Clip Price: Call Us |
| 9 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 9 |
530035138 |
Throttle Return Spring Price: Call Us |
| 10 |
29-5600 |
DISCONTINUED Price: Call Us |
| 10 |
530035015 |
Throttle Valve Screw Price: $1.99 |
| 11 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 11 |
530035132 |
Shaft Ass'y. - Throttle Price: Call Us |
| 12 |
530035023 |
Idle Needle Spring Price: $0.99 |
| 13 |
530035141 |
Idle Needle Price: $2.99 |
| 14 |
530035188 |
WT-141 - T1 This part replaces 530035139. Price: $1.99 |
| 15 |
503117001 |
Needle This part replaces 530035106. Price: $7.99 |
| 16 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 17 |
530035036 |
Hi Speed Needle Spring Price: Call Us |
| 18 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 20 |
530035016 |
Metering Lever Pin Screw Price: $2.99 |
| 21 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 22 |
530035042 |
Circuit Plate Price: $3.33 |
| 24 |
530035151 |
Metering Diaphragm Gasket Price: $1.99 |
| 25 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 26 |
530035153 |
Metering Cover & Throttle Shaft Clip Ass'y. Screw Price: $3.33 |
| 27 |
530035149 |
Metering Diaphragm Cover Price: $3.33 |
| 28 |
530035185 |
Carb Kwik Repair Kit Price: $24.99 |
