| Ref | Part Number | Description |
|---|
| 1 |
125-9618-03 |
HINGE-DOOR, RH Price: $37.15 |
| 1 |
539130394 |
FUEL CAP, GENERIC This part replaces 539106188. Price: $27.99 |
| 2 |
130-5691 |
RH DOOR ASM Price: $1,198.10 |
| 2 |
539102845 |
SPRING Price: $2.99 |
| 3 |
125-7389-03 |
FRAME-DOOR, RH Price: $352.75 |
| 3 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 4 |
121-8331 |
GASKET-HANDLE Price: $15.02 |
| 4 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
596435501 |
Bolts This part replaces 539102335. Price: $3.99 |
| 6 |
125-9982 |
BUSHING-FLANGE Price: $1.76 |
| 6 |
539102502 |
STUD, 5/16C Price: $8.99 |
| 7 |
125-9676 |
WASHER-BACKUP Price: $1.70 |
| 8 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 9 |
125-9520 |
SCREW-SHOULDER, HSH Price: $1.83 |
| 9 |
539104410 |
FUEL TANK RT Price: $279.99 |
| 10 |
539922091 |
FUEL LINE Price: $3.99 |
| 11 |
539102679 |
FUEL VALVE Price: $49.99 |
| 11 |
98-3104 |
STUD-BALL Price: $4.61 |
| 12 |
121-8390 |
LATCH-RH Price: $63.03 |
| 12 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 13 |
121-8630 |
HANDLE ASM Price: $121.56 |
| 13 |
539105280 |
HOSE 35" Price: $11.99 |
| 14 |
33103-025 |
SCREW-HHF Price: $0.54 |
| 14 |
539108212 |
FUEL LINE 13" Price: $1.99 |
| 15 |
3234-21 |
SCREW-HHF Price: $2.19 |
| 15 |
539102650 |
HOSE BARB 90 DEGREE Price: $4.99 |
| 16 |
104-7201 |
NUT-HF Price: $0.69 |
| 16 |
539104897 |
TANK SPACER Price: $7.99 |
