| Ref | Part Number | Description |
|---|
| 1 |
121327X |
PULLEY TRANSAXLE Price: Call Us |
| 1 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
12000004 |
RING Price: Call Us |
| 2 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 3 |
2228M |
SUB= 2228M1 Price: Call Us |
| 3 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 4 |
820-010B |
TRANSAXLE 6 SP Price: Call Us |
| 4 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 5 |
72140506 |
BOLT Price: Call Us |
| 5 |
93-6337 |
SCREW Price: $9.77 |
| 6 |
19111214 |
WASHER Price: Call Us |
| 6 |
99-8701 |
ROTATING KIT This part replaces 93-6322. Price: $1,722.95 |
| 7 |
105-2856 |
PISTON-SERVO Price: $739.56 |
| 7 |
106919X |
PLATE SHIFT LT Price: Call Us |
| 8 |
422707 |
ENGINE B&S 18HP Price: Call Us |
| 8 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 9 |
126197X |
WASHER Price: Call Us |
| 9 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 10 |
100229L |
EXHAUST TUBE T Price: Call Us |
| 10 |
93-6339 |
GASKET Price: $14.34 |
| 11 |
105-2900 |
GASKET-HOUSING Price: $46.30 |
| 11 |
109740X |
REAR BAFFLE T Price: Call Us |
| 12 |
105-2901 |
GASKET-HOUSING, CONTROL Price: $38.61 |
| 12 |
73510600 |
NUT Price: Call Us |
| 13 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 14 |
108373X |
MUFFLER HYT Price: Call Us |
| 14 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 15 |
123190X |
SHIELD HEAT FRT Price: Call Us |
| 15 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 16 |
73350600 |
NUT Price: Call Us |
| 16 |
76-6960 |
BEARING-THRUST This part replaces 60-6170. Price: $23.23 |
| 17 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 17 |
123554X |
V BELT Price: Call Us |
| 18 |
17021008 |
SCREW Price: Call Us |
| 19 |
106279X |
CONTROL KNOB LT Price: Call Us |
| 19 |
323-15 |
SCREW-HH Price: $1.53 |
| 20 |
124378X |
ROD SHIFTER T Price: Call Us |
| 20 |
323-16 |
SCREW-HH Price: $2.89 |
| 21 |
105701X |
WASH-SHFT PLT LT Price: Call Us |
| 21 |
93-6324 |
SCREW Price: $8.89 |
| 22 |
105-2902 |
PLATE-VALVE Price: $561.90 |
| 22 |
19151216 |
WASHER Price: Call Us |
| 23 |
105-2903 |
HOUSING Price: $2,233.91 |
| 23 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 24 |
105-8149 |
ENDCOVER ASM Price: $1,565.24 |
| 24 |
17490612 |
SCREW Price: Call Us |
| 25 |
129921 |
KEEPER.BELT.ENG.L Price: Call Us |
| 25 |
94-3020 |
SHAFT-DRIVE Price: $627.17 |
| 26 |
105-2905 |
O-RING Price: $26.38 |
| 26 |
74760616 |
BOLT Price: Call Us |
| 27 |
19131312 |
WASHER Price: Call Us |
| 27 |
3217-5 |
NUT-HEX Price: $0.25 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 28 |
73680600 |
SUB= 73690600 Price: Call Us |
| 29 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 29 |
8883R |
PEDAL COVER T Price: Call Us |
| 30 |
105-2906 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 30 |
122424X |
SUB= 149001 Price: Call Us |
| 31 |
105-3331 |
SEAL-SHAFT Price: $35.63 |
| 31 |
1572H |
SUB= 2882J Price: Call Us |
| 32 |
105-2907 |
CHARGE PUMP ADAPTER ASM Price: $1,126.94 |
| 32 |
19211616 |
WASHER LT Price: Call Us |
| 33 |
13200300 |
ELBOW Price: Call Us |
| 33 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 34 |
93-6306 |
CONTROL ASM Price: $1,822.55 |
| 35 |
105-2908 |
DISCONTINUED Price: Call Us |
| 35 |
126112X |
SUB= 142600 Price: Call Us |
| 36 |
107-4445 |
DISCONTINUED This part replaces 99-8707. Price: $568.49 |
| 36 |
136715 |
SUB= 140312 Price: Call Us |
| 37 |
105-2909 |
ORIFICE-CONTROL, .036 DIA Price: $20.39 |
| 37 |
109070X |
BELT KEEPER LT Price: Call Us |
| 38 |
105-2910 |
ORIFICE-VALVE, CONTROL Price: $42.23 |
| 38 |
4470J |
SPACER T Price: Call Us |
| 39 |
123674X |
PULLEY.IDLER.FLAT Price: Call Us |
| 40 |
105-2911 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 40 |
74760644 |
BOLT Price: Call Us |
| 41 |
105-2912 |
RING-RETAINING Price: $23.48 |
| 41 |
136906 |
PULLEY ENGINE Price: Call Us |
| 42 |
10040700 |
LOCKWASHER Price: Call Us |
| 42 |
105-2913 |
VALVE-BYPASS Price: $91.51 |
| 43 |
71170768 |
SUB= 150280 Price: Call Us |
| 43 |
94-3030 |
WASHER Price: $6.24 |
| 44 |
93-6336 |
WASHER Price: $3.19 |
| 45 |
8545J |
SUB= 272250 Price: Call Us |
| 47 |
120183X |
NYLON BEARING Price: Call Us |
| 48 |
71040412 |
SUB= 74550412 Price: Call Us |
| 49 |
19091210 |
WASHER LT Price: Call Us |
| 50 |
10040400 |
LOCKWASHER Price: Call Us |
| 51 |
73680500 |
SUB= 73690500 Price: Call Us |
| 52 |
74780544 |
BOLT HEX Price: Call Us |
| 53 |
122109X |
STRAP TORQUE Price: Call Us |
| 54 |
109167X |
BRACKET LT Price: Call Us |
| 55 |
106157X |
PLATE-STRAP LT Price: Call Us |
| 56 |
76020412 |
COTTER PIN Price: Call Us |
| 57 |
133261 |
BRAKE PARK ROD Price: Call Us |
| 58 |
121862X |
ROD BRAKE Price: Call Us |
| 59 |
7733J |
SUB= 71673 Price: Call Us |
| 60 |
106888X |
SPRING ROD LT Price: Call Us |
| 61 |
19131316 |
WASHER Price: Call Us |
| 62 |
123800X |
WASHER Price: Call Us |
| 63 |
74780412 |
SUB= 74780414 Price: Call Us |
| 64 |
13280336 |
PIPE NIPPLE LT Price: Call Us |
| 65 |
127783 |
SUB= 139245 Price: Call Us |
| 66 |
123789X |
ARM IDLER Price: Call Us |
| 67 |
123205X |
RETAIN BELT Price: Call Us |
| 68 |
74760624 |
SUB= 74930624 Price: Call Us |
| 69 |
110812X |
WASHER LT Price: Call Us |
| 70 |
12000039 |
KLIP RING Price: Call Us |
| 73 |
110422X |
SUB= 146682 Price: Call Us |
| 74 |
132773 |
SUB= 133439 Price: Call Us |
| 75 |
17720410 |
SCREW LT Price: Call Us |
| 76 |
132922 |
SPARK ARREST KIT Price: Call Us |
| 77 |
2751R |
CLIP T Price: Call Us |
| 78 |
17490512 |
SCREW Price: Call Us |
| 79 |
109169X |
SUB= 109172X Price: Call Us |
| 80 |
73800600 |
NUT Price: Call Us |
| 81 |
108097X |
SPACER HYT Price: Call Us |
| 82 |
108236X |
BRACKET LT Price: Call Us |
| 83 |
12000053 |
E RING HYT Price: Call Us |
| 84 |
11050600 |
LOCKWASHER Price: Call Us |
| 85 |
9396E |
SQ KEY STD Price: Call Us |
| 87 |
17490624 |
SCREW LT Price: Call Us |
