| Ref | Part Number | Description |
|---|
| 1 |
5-0350 |
Housing Price: Call Us |
| 3 |
322-13 |
SCREW-HH Price: $2.73 |
| 4 |
322-10 |
SCREW-HH Price: $0.70 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 9 |
5-0410 |
Blade Retainer Price: Call Us |
| 11 |
3210-5 |
SCREW-HH Price: $0.54 |
| 12 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 14 |
47-2890 |
BUSHING This part replaces 256-110. Price: $3.19 |
| 15 |
47-2900 |
BUSHING This part replaces 256-109. Price: $3.98 |
| 16 |
47-7260 |
SEAL This part replaces 253-86. Price: $5.36 |
| 17 |
3-0724 |
THRUST WASHER Price: $5.65 |
| 18 |
3-6436 |
WORM GEAR Price: $242.94 |
| 20 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 22 |
3-4738 |
Worm Shaft Price: Call Us |
| 23 |
3-0734 |
GASKET Price: $5.65 |
| 24 |
3-6438 |
Cover Gear Box Price: Call Us |
| 25 |
47-7460 |
BALL BEARING This part replaces 251-144. Price: $51.08 |
| 27 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
321-15 |
SCREW-HH Price: $0.61 |
| 30 |
2-9839 |
Clutch Assembly Price: Call Us |
| 31 |
2-9889 |
Clutch Assembly Price: Call Us |
| 32 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 33 |
5-3681 |
GEAR BOX PULLEY This part replaces 3-6442. Price: Call Us |
| 34 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 35 |
3-6452 |
OUTPUT SHAFT Price: Call Us |
| 36 |
3-6454 |
OUTPUT SHAFT Price: $184.73 |
| 41 |
3220-3 |
NUT-HJ Price: $0.28 |
| 45 |
116-7257 |
BEARING-BALL This part replaces 251-180. Price: $12.33 |
| 46 |
3-6451 |
WHEEL COVER Price: Call Us |
| 48 |
3-6593 |
V-BELT Price: $111.99 |
| 49 |
3-6594 |
Belt Guide Price: Call Us |
| 52 |
32140-18 |
Screw Price: Call Us |
| 53 |
3-6911 |
Arm, Auxiliary Idler Price: Call Us |
| 54 |
322-3 |
SCREW-HH Price: $0.79 |
| 55 |
3-4244 |
PULLEY-IDLER Price: $24.99 |
| 56 |
323-7 |
SCREW-HH Price: $0.65 |
| 57 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 58 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 59 |
322-1 |
SCREW-HH Price: $0.22 |
| 60 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 61 |
3-6598 |
Idler Arm (Incl. Ref. #14) This part replaces 2-9909. Price: Call Us |
| 62 |
256-1 |
BUSHING Price: $21.99 |
| 63 |
3-6468 |
ROLLED SPACER Price: Call Us |
| 64 |
323-10 |
SCREW-HH Price: $0.89 |
| 65 |
3-4243 |
IDLER PULLEY *R Price: Call Us |
| 66 |
3211-8 |
SCREW-HH Price: $3.50 |
| 67 |
3-6471 |
Hook Price: Call Us |
| 68 |
3296-5 |
NUT-HEX Price: $3.09 |
| 70 |
3-6472 |
CONTROL ROD Price: Call Us |
| 71 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 72 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 73 |
3-6473 |
Shroud Price: Call Us |
| 77 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 78 |
3290-211 |
WASHER-SPRING Price: $4.89 |
| 79 |
19-7180 |
Control Bail This part replaces 2-9849. Price: Call Us |
| 80 |
5-2490 |
SCREW-SHOULDER This part replaces 3-1846. Price: $8.25 |
| 81 |
3-6478 |
Control Rod Price: Call Us |
