| Ref | Part Number | Description |
|---|
| 1 |
486281 |
Outlet Adapter, Impeller Housing Price: Call Us |
| 2 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 3 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 4 |
04021-22 |
Lock Nut, 5/16-18 Elastic Stop Grade 8 Price: Call Us |
| 5 |
04112-06 |
Nut, 3/4-16 Spriral Lock Price: Call Us |
| 6 |
486266 |
Pulley, Blower, 6.95 DIA, Double Groove Price: Call Us |
| 7 |
463312 |
Blower Housing, With Decal Price: Call Us |
| 8 |
04063-08 |
Key, 1/4 x 1/4 x 2.0" Price: Call Us |
| 10 |
483304 |
Debris Shield Price: Call Us |
| 11 |
483303 |
Bearing Price: Call Us |
| 13 |
43693 |
Spacer, Bearing Price: Call Us |
| 14 |
43694 |
Protector, Bearing Price: Call Us |
| 15 |
431127 |
Shaft, Spindle Price: Call Us |
| 16 |
04001-175 |
Bolt, Hex Head 5/16-18 x 1-1/2" Grade 8 Price: Call Us |
| 17 |
452925 |
Impeller Weldment Price: Call Us |
| 18 |
486046 |
Bushing, Split Taper 1.125 Bore Price: Call Us |
| 19 |
426338 |
End Plate, Tapered Hub Price: Call Us |
| 20 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 21 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 22 |
04001-07 |
Bolt, Hex Head 1/2-13 x 1.5" Price: Call Us |
| 23 |
483453-11 |
Bearing, Plastic Price: Call Us |
| 24 |
428336 |
Brace Plate, Nozzle Pivot Price: Call Us |
| 25 |
427873 |
Bottom Plate, Pivot Gear Price: Call Us |
| 26 |
486695 |
Outlet Nozzle, Impeller Housing Price: Call Us |
| 27 |
463014 |
Baffle Weldment, Intake, With Decal Price: Call Us |
| 28 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 29 |
04021-08 |
HEX, NUT, ELASTIC STOP LOCK, 1/4-20 Price: Call Us |
| 30 |
04024-03 |
Nut, Push-On 5/16-18 Price: Call Us |
| 31 |
429230 |
Stop Bracket, Nozzle Limit Switch Price: Call Us |
| 32 |
486854 |
Directional Flag, Nozzle Price: Call Us |
| 33 |
486452 |
Bearing Plate, Pivot Gear Price: Call Us |
| 34 |
429236 |
Top Plate, Pivot Gear Price: Call Us |
| 35 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 36 |
485691 |
Plunger Switch, Single Pole Price: Call Us |
| 37 |
487507 |
Motor, Gear Drive Price: Call Us |
| 38 |
04018-04 |
Screw, Cap Serr. Flange, M5-0.8 x 12 Price: Call Us |
| 39 |
04017-15 |
CAP SCREW, 5/16-18 X 1/2" SERRATED FLANGE HEX Price: Call Us |
| 40 |
04001-178 |
Bolt, Hex Head 7/16-20 x 1" Price: Call Us |
| 41 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 42 |
453206 |
Pivot Gear, Nozzle Price: Call Us |
| 43 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 44 |
48030-09 |
Clamp, Cable 1/2" I.D. Price: Call Us |
| 45 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 46 |
486407 |
Wear Disc, Pivot Gear Price: Call Us |
| 47 |
04001-01 |
BOLT, HEX HEAD, 1/4-20 X 3/4 GR.5 Price: Call Us |
| 48 |
428335 |
Bracket, Nozzle Tilt Price: Call Us |
| 49 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 50 |
487299 |
Gear, Chute Motor Price: Call Us |
