| Ref | Part Number | Description |
|---|
| 1 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 1 |
484286 |
Fuel Cap w/ Tether (E.P.A.) Price: Call Us |
| 2 |
37-9600-01 |
SEAT SUPPORT WA This part replaces 37-9600. Price: $351.46 |
| 2 |
484243 |
Fuel Gauge Assembly Price: Call Us |
| 3 |
107-3039 |
PIN-LYNCH This part replaces 3290-243. Price: $6.96 |
| 3 |
484242 |
Grommet, Fuel Gauge Price: Call Us |
| 4 |
37-9580 |
DISCONTINUED Price: Call Us |
| 4 |
463282 |
Fuel Tank Assembly (incl. #2, 3, 5, 6, 17, 18) Price: Call Us |
| 5 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 5 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 6 |
3220-2 |
NUT-JAM Price: $0.50 |
| 6 |
486181 |
Valve, Fuel Shutoff w/Screen Price: Call Us |
| 7 |
3253-24 |
WASHER-LOCK/SP Price: $0.37 |
| 7 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose I.D. Price: Call Us |
| 8 |
2411-33 |
BALLJOINT-RH (W/GROMMET) This part replaces 37-9570. Price: $24.45 |
| 8 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) Price: Call Us |
| 9 |
3217-7 |
NUT-HEX Price: $0.28 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
323-12 |
SCREW-HH Price: $1.14 |
| 12 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 12 |
48059-05 |
Clamp, Vapor Recovery Hose 3/16" Price: Call Us |
| 13 |
37-9590 |
DISCONTINUED Price: Call Us |
| 13 |
484345 |
Hose, Vapor Recovery 3/16" Price: Call Us |
| 14 |
48030-11 |
Clamp, Double Cable 5/8" ID. Price: Call Us |
| 14 |
71-4490 |
SEAT SUPT BRKT WA *R This part replaces 27-9830. Price: $142.74 |
| 15 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 15 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 16 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 16 |
3217-6 |
NUT-HEX Price: $1.19 |
| 17 |
322-4 |
SCREW-HH Price: $0.35 |
| 17 |
484285 |
Grommet, Viton, Price: Call Us |
| 18 |
484333 |
Remote Vent, No Valve Price: Call Us |
| 19 |
48059-02 |
CLAMP, FUEL HOSE(KAWASAKI ONLY) Price: Call Us |
| 20 |
484347 |
Hose, 1/4" Vapor Recovery (order by inch) Price: Call Us |
| 21 |
484279-01 |
Tube, Fuel Tank Insert - 4" Price: Call Us |
| 22 |
484343-01 |
Mender, 1/4 x 3/16 w/0.02 Hole Price: Call Us |
| 23 |
484287 |
Carbon Canister - SVR-36A / SVR-48V Price: Call Us |
| 24 |
48136-17 |
Clamp, 3-1/2" Max. Dia. Price: Call Us |
| 25 |
452176 |
Bracket, Canister Mounting Price: Call Us |
| 26 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 27 |
48030-09 |
Clamp, Cable 1/2" I.D. Price: Call Us |
| 28 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 29 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 484297 |
Fuel |
Cap w/Tethered - California Models Only Price: Call Us 484297 |
