| Ref | Part Number | Description |
|---|
| 1 |
532176555 |
CONTROL BAR Price: $7.99 |
| 1 |
93-9991-03 |
BRACKET-CLUTCH ANCHOR This part replaces 93-9991. Price: $15.31 |
| 2 |
321-3 |
SCREW-HH Price: $0.28 |
| 3 |
532174291 |
HANDLE.LOWER.BLACK This part replaces 532174110. Price: $32.99 |
| 3 |
93-9990-03 |
GUARD-FLYWHEEL This part replaces 93-9990. Price: $11.33 |
| 4 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 4 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532179585. Price: $7.99 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 5 |
93-9997-03 |
DISCONTINUED This part replaces 93-9997. Price: Call Us |
| 6 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $5.99 |
| 6 |
93-9992 |
DISCONTINUED Price: Call Us |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 7 |
93-9949 |
DISCONTINUED Price: Call Us |
| 9 |
532154132 |
BRACKET.ASM.HOUSING.EZ.MUL Price: $5.99 |
| 10 |
581825801 |
DOOR.MULCH.21".REAR.PUSH.GRAY This part replaces 532185589. Price: $11.99 |
| 11 |
532176556 |
ENGINE ZONE CONTROL CABLE Price: $19.99 |
| 12 |
532750634 |
SCREW Price: $2.99 |
| 13 |
532430034 |
BRACKET.UPSTOP.RT This part replaces 532125203. Price: $5.99 |
| 14 |
532185588 |
KNOB.HANDLE.STAR.HUSQ.GRAY Price: $5.99 |
| 15 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 17 |
532165946 |
BRACKET.SUPPORT.21.DOMED.BLACK This part replaces 532174112. Price: $6.99 |
| 18 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 19 |
532186578 |
ARM.ASM.AXLE.LR/RF.5/9POS.BZP This part replaces 532189278. Price: $7.99 |
| 20 |
532186577 |
ARM.ASM.AXLE.RR/LF.5/9POS.BZP This part replaces 532189277. Price: $8.99 |
| 21 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532188987. Price: $11.99 |
| 22 |
532168360 |
SPRING.SELECTOR.5/9POS This part replaces 532168599. Price: $3.99 |
| 24 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 25 |
586559801 |
KIT.BRACKET.HANDLE/REAR.DOOR This part replaces 532174105. Price: $89.99 |
| 26 |
586559801 |
KIT.BRACKET.HANDLE/REAR.DOOR This part replaces 532174106. Price: $89.99 |
| 27 |
817600406 |
SCREW 1/4X20 This part replaces 532851856. Price: $2.99 |
| 28 |
532152124 |
TORSION SPRING Price: $5.99 |
| 29 |
532407494 |
BRACKET.ADJ.5POS.ADS This part replaces 532165704. Price: $3.99 |
| 30 |
532183901 |
SPACER.34X1.38X.22 Price: $5.99 |
| 31 |
589482402 |
DEFLECTOR.CLIPPING.21.PUSH.BLK This part replaces 532185595. Price: $8.99 |
| 32 |
532180077 |
SELECTOR SPRING, REAR This part replaces 532185716. Price: $4.99 |
| 33 |
532185574 |
SELECTOR KNOB Price: $5.99 |
| 34 |
532181214 |
ARM.ASM.AXLE.10".LR This part replaces 532185718. Price: $8.99 |
| 36 |
532160828 |
SHOULDER BOLT Price: $3.99 |
| 37 |
532180541 |
WHEEL 8 X 2 BLACK BALL BEARING Price: $21.99 |
| 39 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 40 |
532194642 |
FRAME.BAG.21.REAR.DOME This part replaces 532188813. Price: $37.99 |
| 41 |
532088652 |
HINGE SCREW Price: $3.99 |
| 42 |
532165766 |
SPRING (LH) Price: $5.99 |
| 43 |
532165767 |
SPRING (RH) Price: $4.99 |
| 44 |
532184193 |
BOLT Price: $4.99 |
| 45 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 47 |
532150182 |
CAP.HUB.ARC.SPOKE.8".LP This part replaces 532180626. Price: $3.99 |
| 48 |
532181215 |
ARM.ASM.AXLE.10".RR.5/9 This part replaces 532185717. Price: $8.99 |
| 49 |
532180183 |
WHEEL.10X2.PR.HITRAC.BLACK Price: $32.99 |
| 50 |
532410666 |
GBAG.22510010.BLK.GEN This part replaces 532189788. Price: $69.99 |
| 51 |
532147286 |
ROD.HINGE.COMBI-C Price: $6.99 |
| 53 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 54 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 55 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 56 |
532189028 |
BLADE.21.PUSH/RWGD/FWG Price: $19.99 |
| 57 |
532418373 |
ADAPTER.BLADE.W/KEY.25MM.CE This part replaces 532184590. Price: $9.99 |
| 61 |
532180123 |
HUBCAP.10.MAG.SILVER Price: $3.99 |
| 62 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 65 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
| 66 |
532197480 |
O-RING..070X.487.NEOPRENE This part replaces 532188152. Price: $3.99 |
| 67 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532164265. Price: $4.99 |
