| Ref | Part Number | Description |
|---|
| 1 |
2412-73 |
CLAMP-R Price: $2.56 |
| 1 |
530015773 |
Screw Price: $1.99 |
| 2 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 2 |
530027529 |
Air Filter Cover Price: $3.42 |
| 3 |
38-2730 |
DISCONTINUED Price: Call Us |
| 3 |
530027530 |
Air Filter Price: $1.99 |
| 4 |
38-2720 |
DISCONTINUED Price: Call Us |
| 4 |
530015849 |
Screw Price: $1.99 |
| 5 |
38-2710 |
DISCONTINUED Price: Call Us |
| 5 |
530015852 |
Spacer Price: $1.99 |
| 6 |
38-2700 |
DISCONTINUED Price: Call Us |
| 6 |
530015254 |
Wave Washer Price: $1.99 |
| 7 |
38-2740 |
DISCONTINUED Price: Call Us |
| 7 |
530038103 |
Choke Shutter Price: $1.99 |
| 8 |
38-2750 |
DISCONTINUED Price: Call Us |
| 8 |
530027527 |
Air Filter Plate (Type 1) Price: $2.99 |
| 8 |
530037930 |
Air Filter Plate (Type 2 & 3) Price: $2.99 |
| 9 |
38-2570 |
DISCONTINUED Price: Call Us |
| 9 |
530069247 |
Fuel Line Kit (Fuel LineType 1) Price: $3.99 |
| 9 |
530069571 |
Fuel Line Kit (Return LineType 2 & 3) Price: $2.99 |
| 10 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 10 |
530069651 |
Carburetor (40T, 50T (WT298A) Type 2 & 3) Price: $18.32 |
| 10 |
530095646 |
Assy-Fuel Pickup This part replaces 530014362. Price: $2.99 |
| 10 |
545081825 |
KIT CARBURETOR ASSY This part replaces 530035259. Price: $49.99 |
| 11 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 12 |
38-2760 |
DISCONTINUED Price: Call Us |
| 12 |
530019156 |
Carburetor Gasket Price: $3.99 |
| 13 |
38-2790 |
DISCONTINUED Price: Call Us |
| 13 |
530014347 |
Fuel Cap Ass'y. Price: $4.99 |
| 14 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 14 |
530015775 |
Screw Price: $1.99 |
| 14 |
530037497 |
Throttle Cable Ass'y., Model 114 This part replaces 530027549. Price: $3.76 |
| 15 |
37-7340 |
DISCONTINUED Price: Call Us |
| 16 |
2412-10 |
CLAMP-R Price: $2.78 |
| 16 |
530027982 |
Shroud & Tank Ass'y. (Type 1) Price: $15.84 |
| 16 |
530047086 |
Shroud & Tank Ass'y. (Type 2 & 3) Price: $34.99 |
| 17 |
530019154 |
Crankcase/Shroud Gasket Price: $1.99 |
| 17 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
530027593 |
Reed Price: $1.99 |
| 19 |
18-2970 |
CLIP-FUEL LINE Price: $8.67 |
| 19 |
530010960 |
Connecting Rod Ass'y. (40T, 50, 50T) Price: $14.99 |
| 19 |
530027594 |
Reed Stop Price: $1.99 |
| 20 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 21 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 22 |
304-61 |
CLAMP-HOSE Price: $6.08 |
| 22 |
530015126 |
Flywheel Key Price: $1.99 |
| 23 |
237-101 |
O-RING This part replaces 237-123. Price: $2.80 |
| 23 |
530015772 |
Screw Price: $1.99 |
| 24 |
353-703 |
DISCONTINUED Price: Call Us |
| 24 |
530015780 |
Screw Price: $1.99 |
| 25 |
38-5820 |
DISCONTINUED Price: Call Us |
| 25 |
530027546 |
Switch Insulator Price: $2.99 |
| 26 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 26 |
530027547 |
Lead Wire Price: $1.99 |
| 27 |
3-3760 |
DISCONTINUED Price: Call Us |
| 27 |
530015771 |
Screw Price: $1.99 |
| 28 |
32146-13 |
NUT-HEX Price: $3.49 |
| 29 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 29 |
530027545 |
Switch Ramp Price: $1.99 |
| 30 |
2412-6 |
CLAMP-HOSE Price: $4.57 |
| 30 |
530038309 |
Switch Button Price: $1.99 |
| 31 |
325-4 |
SCREW-HH Price: $0.95 |
| 31 |
530027959 |
Switch Spring Price: $1.99 |
| 31 |
530071705 |
Assy-C'case/C'shaft This part replaces 530014015. Price: $29.99 |
| 32 |
3296-24 |
NUT-HEX Price: $4.44 |
| 33 |
325-5 |
SCREW-HH Price: $1.20 |
| 33 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 34 |
323-18 |
SCREW-HH Price: $0.82 |
| 34 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 34 |
530025875 |
Piston Ring (40T, 50, 50T) Price: $4.99 |
| 35 |
321-10 |
SCREW-HH Price: $1.29 |
| 36 |
38-3110 |
DISCONTINUED Price: Call Us |
| 36 |
530019267 |
GASKET CYL W/ ADHESIVE This part replaces 530019178. Price: $2.99 |
| 36 |
530069899 |
Piston Kit This part replaces 530069275. Price: $19.99 |
| 37 |
38-3100 |
DISCONTINUED Price: Call Us |
| 38 |
321-4 |
SCREW-HH Price: $0.99 |
| 39 |
237-79 |
O-RING Price: $5.46 |
| 39 |
530032103 |
Inner Bearing Price: Call Us |
| 40 |
37-4910 |
DISCONTINUED Price: Call Us |
| 40 |
530015787 |
Retaining Ring Price: $1.99 |
| 41 |
530019158 |
Crankshaft Seal Price: $2.99 |
| 42 |
530032102 |
Outer Bearing Price: $8.99 |
| 43 |
530015789 |
Crankshaft Retaining Ring Price: $2.99 |
| 44 |
530015717 |
Screw Price: $1.99 |
| 45 |
530027781 |
Muffler Guard Price: $1.99 |
| 46 |
530069310 |
Muffler Kit This part replaces 530069257. Price: $9.99 |
| 47 |
530036409 |
Muffler Attachment Spring Price: $1.99 |
| 47 |
530069626 |
Cylinder (40T, 50, 50T) Price: $1.92 |
| 49 |
530001624 |
Screw (40, 40T, 50T) Price: $1.99 |
| 49 |
530030077 |
Spark Plug Price: $2.27 |
| 51 |
530015816 |
Screw This part replaces 530015128. Price: $1.99 |
| 51 |
530039134 |
Ignition Module Kit Price: $44.99 |
| 51 |
530039189 |
Flywheel Ass'y. (20, 40, 40T, 50, 50T) Price: $22.99 |
| 54 |
530014009 |
Pulley Housing Ass'y. 40, 40T, 50, 50T Price: $5.84 |
| 54 |
530027948 |
Fan Housing (40, 40T, 50, 50T) Price: $12.99 |
| 57 |
545008010 |
STARTER SPRING This part replaces 530029395. Price: $3.99 |
| 58 |
530027569 |
Starter Handle Price: $1.99 |
| 59 |
530069232 |
Rope Kit Price: $3.99 |
| 60 |
530094189 |
Clutch Washer- 40, 40T, 50, 50T Price: $2.99 |
| 61 |
530069254 |
Clutch Ass'y. Kit- 40, 40T, 50, 50T Price: $8.99 |
| 62 |
530015796 |
Washer40, 40T, 50, 50T Price: $1.99 |
| 63 |
530001733 |
Nut-40, 40T, 50, 50T Price: $2.99 |
| 64 |
530014017 |
Clutch Housing-40, 40T, 50, 50T Price: $24.99 |
| 65 |
530016080 |
Screw-Rope Retaining Price: $1.99 |
| 66 |
530015767 |
Screw Price: $1.99 |
| 68 |
530015770 |
Screw Price: Call Us |
| 69 |
530015769 |
Screw Price: $1.99 |
| 70 |
530015496 |
Screw Price: $1.99 |
| 71 |
530027523 |
Retainer Price: $2.99 |
| 72 |
530015768 |
Locknut Price: $1.99 |
| 74 |
952701612 |
Spark Arrestor Kit Price: Call Us |
| 75 |
530027511 |
Spacer 40, 40T, 50,, 50T Price: $4.99 |
| 76 |
530016030 |
Washer This part replaces 530347987. Price: $1.99 |
| 77 |
530027986 |
Instruction Decal (Type 1) Price: $3.33 |
| 77 |
530037742 |
Instruction Decal (Type 2) Price: $3.33 |
| 77 |
530038844 |
Instruction Decal (Type 3) Price: $3.33 |
| 81 |
530038874 |
Primer Bulb Ass'y. Type 2 & 3 Price: $5.99 |
| 82 |
530016091 |
ScrewPrimer Type 2 & 3 Price: $1.99 |
| 83 |
530015882 |
ScrewStarter Spring Type 3 Price: $1.99 |
