| Ref | Part Number | Description |
|---|
| 1 |
3220-2 |
NUT-JAM Price: $0.50 |
| 1 |
532123634 |
Free Wheel Control Assembly Price: $6.49 |
| 2 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 2 |
819092016 |
Washer 9/32 x 1-1/4 x 16 Gauge Price: $2.99 |
| 3 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 3 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 4 |
532121188 |
Bracket, Pnt., Mounting, Differential Price: $4.42 |
| 4 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 5 |
874780416 |
Bolt Hex Fin 1/4-20 unc x 1 Gr. 5 This part replaces 874780412. Price: $3.99 |
| 5 |
93-6337 |
SCREW Price: $9.77 |
| 6 |
532121186 |
Fan, Hydro, 8" Price: $16.78 |
| 6 |
99-8701 |
ROTATING KIT This part replaces 93-6322. Price: $1,722.95 |
| 7 |
105-2856 |
PISTON-SERVO Price: $739.56 |
| 7 |
532121180 |
Pulley, Transaxle Price: $50.61 |
| 8 |
532121211 |
Standoff, Fan, Hydro Price: $13.99 |
| 8 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 9 |
532121182 |
Guard Assembly, Belt Price: $5.50 |
| 9 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 10 |
532121431 |
Differential Assembly Price: $712.56 |
| 10 |
93-6339 |
GASKET Price: $14.34 |
| 11 |
105-2900 |
GASKET-HOUSING Price: $46.30 |
| 11 |
532121430 |
Pump Assembly Price: $809.77 |
| 12 |
105-2901 |
GASKET-HOUSING, CONTROL Price: $38.61 |
| 12 |
874760572 |
Bolt, Hex, Fin 5/16-18 UNC x 4-1/2 Price: Call Us |
| 13 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 13 |
506774701 |
CONTAINER This part replaces 532121323. Price: $51.99 |
| 14 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 14 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 15 |
532121250 |
Spring, Compression Price: $3.99 |
| 15 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 16 |
76-6960 |
BEARING-THRUST This part replaces 60-6170. Price: $23.23 |
| 16 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 This part replaces 874760612. Price: $3.99 |
| 17 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 17 |
873680600 |
Nut 3/8-16 UNC Price: $1.99 |
| 18 |
810040500 |
Washer, Lock Price: $2.99 |
| 19 |
323-15 |
SCREW-HH Price: $1.53 |
| 19 |
532071673 |
Cap Price: $3.99 |
| 20 |
323-16 |
SCREW-HH Price: $2.89 |
| 20 |
532007605 |
BOLT This part replaces 532124815. Price: $3.99 |
| 21 |
532120529 |
Washer, Nylon Price: $2.99 |
| 21 |
93-6324 |
SCREW Price: $8.89 |
| 22 |
105-2902 |
PLATE-VALVE Price: $561.90 |
| 23 |
105-2903 |
HOUSING Price: $2,233.91 |
| 24 |
105-2904 |
BACKPLATE Price: $1,515.44 |
| 25 |
94-3020 |
SHAFT-DRIVE Price: $627.17 |
| 26 |
105-2905 |
O-RING Price: $26.38 |
| 27 |
3217-5 |
NUT-HEX Price: $0.25 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 30 |
105-2906 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 31 |
105-3331 |
SEAL-SHAFT Price: $35.63 |
| 32 |
105-2907 |
CHARGE PUMP ADAPTER ASM Price: $1,126.94 |
| 33 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 35 |
105-2908 |
DISCONTINUED Price: Call Us |
| 36 |
107-4445 |
DISCONTINUED This part replaces 99-8707. Price: $568.49 |
| 37 |
105-2909 |
ORIFICE-CONTROL, .036 DIA Price: $20.39 |
| 38 |
105-2910 |
ORIFICE-VALVE, CONTROL Price: $42.23 |
| 40 |
105-2911 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 41 |
105-2912 |
RING-RETAINING Price: $23.48 |
| 42 |
105-2913 |
VALVE-BYPASS Price: $91.51 |
| 43 |
94-3030 |
WASHER Price: $6.24 |
| 44 |
93-6336 |
WASHER Price: $3.19 |
