| Ref | Part Number | Description |
|---|
| 1 |
138-6917 |
ENGINE-YANMAR, 4TNV86CT-DTR Price: $20,763.34 |
| 1 |
582733302 |
PLATE.PNT.ENGINE.PZ/PZT.EDIP Price: $59.99 |
| 2 |
539113437 |
CLUTCH, 150 FT/LBS Price: $399.99 |
| 3 |
532178151 |
GASKET This part replaces 586839701. Price: $4.99 |
| 4 |
121-3061 |
PIPE-EXHAUST Price: $77.04 |
| 4 |
539118911 |
PIPE NIPPLE 3/8 X 3 Price: $5.99 |
| 5 |
121-3058 |
GASKET-EXHAUST Price: $19.54 |
| 5 |
522837001 |
PLUG, DRAIN 3/8 NPTF Price: $2.99 |
| 6 |
33004-00 |
NUT-HF Price: $0.34 |
| 6 |
510019801 |
PULLEY, ENGINE Price: $49.99 |
| 7 |
539119680 |
ADAPTER, OIL DRAIN Price: $17.99 |
| 7 |
99-5414 |
STRAP-CLEANER, AIR Price: $48.46 |
| 8 |
99-5410 |
AIR CLEANER ASM Price: $381.32 |
| 9 |
104-3563 |
INDICATOR Price: $58.60 |
| 9 |
539105308 |
KEY 1/4 SQ X 1.0 Price: $3.99 |
| 10 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 10 |
539910210 |
KEY 1/4 SQ X 2 Price: $4.99 |
| 11 |
322-6 |
SCREW-HH Price: $0.45 |
| 11 |
525750301 |
MUFFLER, 29HP KAW FX751V-850V Price: $329.99 |
| 12 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 13 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 13 |
525313902 |
Spacers This part replaces 525313901. Price: $14.99 |
| 14 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 14 |
597180803 |
Stop This part replaces 522676702. Price: $11.99 |
| 15 |
18-2130 |
CLAMP Price: $5.63 |
| 15 |
505280001 |
TIE WRAP, 8-3/8", W/CLIP Price: $2.99 |
| 16 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 16 |
581332805 |
Bolts This part replaces 581332801. Price: $2.99 |
| 17 |
121-3060 |
FLANGE-EXHAUST Price: $113.53 |
| 17 |
574233802 |
Hardware This part replaces 574233801. Price: $2.99 |
| 18 |
121-3142 |
HOSE-AIR CLEANER, OUTLET Price: $83.16 |
| 18 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 19 |
596436601 |
Screws This part replaces 539104867. Price: $1.99 |
| 20 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 20 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 21 |
104-7201 |
NUT-HF Price: $0.69 |
| 21 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 22 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 23 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 24 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 25 |
539125626 |
BLADE WASHER Price: $6.99 |
