| Ref | Part Number | Description |
|---|
| 1 |
107-0807 |
VALVE-FLUSHING, RH Price: $129.44 |
| 1 |
165892 |
Mower Deck Assembly, 42" Price: Call Us |
| 2 |
107-0857 |
PLUG Price: $31.81 |
| 2 |
72140506 |
Bolt Price: Call Us |
| 3 |
107-0817 |
O RING-PLUG Price: $3.09 |
| 3 |
138017 |
Bracket Asm Fr. Sway Bar 3/42 Price: Call Us |
| 4 |
107-0802 |
CASE-CENTER Price: $1,497.06 |
| 4 |
165460 |
Bracket Asm Deck 42" Sway Bar Price: Call Us |
| 5 |
107-0858 |
U-NUT Price: $2.71 |
| 5 |
4939M |
Retainer Spring Price: Call Us |
| 6 |
107-0805 |
PLATE-VALVE Price: $114.64 |
| 6 |
178024 |
Bar Sway Deck Price: Call Us |
| 7 |
107-0824 |
CYLINDER BLOCK ASM Price: $1,216.33 |
| 8 |
107-0830 |
PLATE-THRUST Price: $77.36 |
| 8 |
850857 |
Bolt 3/8-24 x 1.25 Gr. 8 patched Price: Call Us |
| 9 |
10030600 |
Washer, Lock Price: Call Us |
| 9 |
92-0765 |
PIN-PARALLEL Price: $3.03 |
| 10 |
107-0859 |
BOLT Price: $1.56 |
| 10 |
140296 |
Washer, Hardened (The following Blades are available) Price: Call Us |
| 11 |
107-0858 |
U-NUT Price: $2.71 |
| 11 |
134149 |
Blade, Mulching 42†Std (for mulching mowers only) Price: Call Us |
| 11 |
138971 |
Blade Mower 42†Hi-Lift (for bagging and discharging) Price: Call Us |
| 11 |
139775 |
Blade Mulching 42†Premium (For better wear when mulching) Price: Call Us |
| 12 |
120-0008 |
CONTROL ARM KIT This part replaces 107-0831. Price: $153.36 |
| 13 |
107-0832 |
SIDE COVER ASM Price: $444.99 |
| 13 |
137645 |
Shaft As sem bly, Mandrel, Vented Price: Call Us |
| 14 |
107-0829 |
WASHER Price: $35.71 |
| 14 |
128774 |
Housing, Mandrel, Vented Price: Call Us |
| 15 |
107-0809 |
HOUSING-PUMP Price: $4,600.07 |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 16 |
107-0826 |
BEARING Price: $32.70 |
| 16 |
174493 |
Stripper, Mandrel Deck Price: Call Us |
| 17 |
107-0821 |
BEARING Price: $40.03 |
| 18 |
107-0838 |
BEARING Price: $62.42 |
| 18 |
72140505 |
Bolt, Carriage 5/16-18 x 5/8 Price: Call Us |
| 19 |
107-0860 |
BOLT Price: $2.27 |
| 19 |
132827 |
Bolt, Shoulder Price: Call Us |
| 20 |
159770 |
Baffle, Vortex Price: Call Us |
| 21 |
73680500 |
Nut Price: Call Us |
| 23 |
107-0861 |
PLUG-NPTF Price: $11.67 |
| 23 |
177563 |
Bracket, Deflector Mower 42" Price: Call Us |
| 24 |
105304X |
Cap, Sleeve 80 x 112 Blk Mower Price: Call Us |
| 24 |
237-79 |
O-RING This part replaces 107-0862. Price: $5.46 |
| 25 |
107-0867 |
PLUG Price: $14.59 |
| 25 |
123713X |
Spring, Torsion, Deflector 2 52 Price: Call Us |
| 26 |
107-0812 |
PIPE Price: $75.78 |
| 26 |
110452X |
Nut, Push Phos & Oil Price: Call Us |
| 27 |
107-0852 |
CENTER CASE SEAL KIT Price: $12.50 |
| 27 |
130968X428 |
Shield, Deflector 42" Blk Price: Call Us |
| 28 |
107-0813 |
SPACER Price: $8.69 |
| 28 |
19111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: Call Us |
| 29 |
107-0853 |
PUMP HOUSING SEAL KIT Price: $190.09 |
| 29 |
131491 |
Rod, Hinge 42" 6 75 W/G Price: Call Us |
| 30 |
107-0828 |
PLATE-SWASH Price: $639.83 |
| 30 |
173984 |
Screw Thdrol Price: Call Us |
| 31 |
107-0808 |
VALVE-BYPASS Price: $86.68 |
| 31 |
187690 |
Washer, Spacer Mower Vented Price: Call Us |
| 32 |
107-0804 |
VALVE-REAR Price: $414.56 |
| 32 |
153535 |
Pulley, Mandrel Price: Call Us |
| 33 |
107-0803 |
VALVE-FRONT Price: $414.56 |
| 33 |
400234 |
Nut, Toplock Price: Call Us |
| 34 |
107-0863 |
BOLT Price: $1.22 |
| 34 |
72110612 |
Bolt Carr SH 3/8-16 x 1-1/2 Gr.5 Price: Call Us |
| 35 |
107-0806 |
VALVE-FLUSHING, LH Price: $129.44 |
| 36 |
131494 |
Pulley, Idler, Flat Price: Call Us |
| 40 |
73900600 |
Nut Lock 3/8-16 Price: Call Us |
| 44 |
140088 |
Guard, Mandrel, LH Price: Call Us |
| 45 |
4497H |
Retainer Price: Call Us |
| 46 |
137729 |
Screw, Thdrol 1/4-20 x 5/8 T Price: Call Us |
| 48 |
133944 |
Washer, Hardened Price: Call Us |
| 52 |
139888 |
Bolt, Shoulder 5/16-18 unc Price: Call Us |
| 53 |
184907 |
Arm Assembly, Pad, Brake Price: Call Us |
| 54 |
178515 |
Washer, Hardened Price: Call Us |
| 55 |
155046 |
Arm, Idler Price: Call Us |
| 56 |
165723 |
Spacer, Retainer Price: Call Us |
| 59 |
141043 |
Guard TUV Idler Price: Call Us |
| 67 |
106932X |
Knob Round Price: Call Us |
| 68 |
144959 |
V-Belt, 42" Mower Price: Call Us |
| 111 |
179292 |
Bracket Wheel Gauge LH Price: Call Us |
| 112 |
179293 |
Bracket Wheel Gauge RH Price: Call Us |
| 113 |
17000510 |
Bolt 5/16-8 Price: Call Us |
| 116 |
4898H |
Bolt Shoulder Price: Call Us |
| 117 |
188606 |
Wheel Gauge Price: Call Us |
| 118 |
73930600 |
Nut Center Lock 3/8-16 Price: Call Us |
| 119 |
19121414 |
Washer 3/8- x 7/8 x 14 Ga. Price: Call Us |
| 142 |
165890 |
Arm Spring Brake Mower Price: Call Us |
| 143 |
157109 |
Bracket Arm Idler 42" Price: Call Us |
| 144 |
158634 |
Keeper Belt 42" Clutch Cable Price: Call Us |
| 145 |
165888 |
Pulley Idler Flat Price: Call Us |
| 146 |
171977 |
Bolt Carriage Idler Price: Call Us |
| 147 |
131335 |
Spring Extension Price: Call Us |
| 148 |
169022 |
Spring Return Idler Price: Call Us |
| 149 |
165898 |
Retainer Spring Yellow Price: Call Us |
| 150 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 152 |
169676 |
Clutch Cable 42" Price: Call Us |
| 158 |
17720408 |
Screw Hex Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 159 |
72140614 |
Bolt Rdhd Sqn 3/8-16 unc x 1-3/4 Price: Call Us |
| 184 |
19131410 |
Washer 13/32 x 7/8 x 10 Ga. Price: Call Us |
| 185 |
188234 |
Head Asm Cable Clutch Price: Call Us |
