| Ref | Part Number | Description |
|---|
| 1 |
105-7902 |
HYD HOSE ASM This part replaces 92-7556. Price: $77.63 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
IH-384719-R2 |
PAD-BRAKE LINING This part replaces IH-384719-R1. Price: $22.47 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
92-7560 |
HYD HOSE ASM Price: $99.17 |
| 2 |
IH-384717-R11 |
DISC Not Available Price: |
| 3 |
120-6272 |
HYD MOTOR ASM This part replaces 92-7387. Price: $846.73 |
| 3 |
IH-384720-R2 |
RETAINER Not Available Price: |
| 4 |
237-79 |
O-RING Price: $5.46 |
| 4 |
IH-378031-R1 |
RING Not Available Price: |
| 5 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 5 |
IH-17018-R1 |
BALL 9/16 Not Available Price: |
| 6 |
237-30 |
O-RING Price: $2.50 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
IH-384721-R1 |
BRAKE ROD PUSH Not Available Price: |
| 7 |
105-7901 |
HYD HOSE ASM This part replaces 92-7555. Price: $185.30 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
IH-384722-R1 |
Pin, Brake Lever Pivot Price: Call Us |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
92-7559 |
HYD HOSE ASM Price: $121.91 |
| 8 |
IH-384723-R1 |
LEVER Not Available Price: |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
69-8930 |
WASHER Price: $0.81 |
| 9 |
IH-384724-R1 |
ROD Not Available Price: |
| 10 |
None |
Pedal Assy, Clutch & Brake |
| 10 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 11 |
None |
Arm, Clutch & Brake Pedal |
| 11 |
69-8960 |
SPACER Price: $5.29 |
| 12 |
240-5 |
GROMMET Price: $13.66 |
| 13 |
340-70 |
NUT-LOCK Price: $2.10 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
93-4216 |
TUBE ASM Price: $98.51 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
93-4223 |
FRONT DRAIN TUBE ASM Price: $94.84 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 16 |
93-4222 |
DRAIN RETURN TUBE ASM Price: $85.32 |
| 17 |
93-4219 |
TUBE ASM Price: $116.65 |
| 18 |
105-7903 |
HYD HOSE ASM This part replaces 92-7649. Price: $174.38 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
99-5614 |
HYD HOSE ASM This part replaces 93-4201. Price: $103.23 |
| 20 |
237-22 |
O-RING Price: $2.43 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
93-9151 |
FITTING-HYD Price: $40.90 |
| 22 |
237-21 |
O-RING Price: $0.70 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 24 |
237-78 |
O-RING Price: $3.85 |
| 25 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
93-4217 |
DISCONTINUED Price: Call Us |
| 27 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
93-9783 |
O-RING Price: $2.30 |
| 29 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 30 |
322-7 |
SCREW-HH Price: $0.89 |
| 31 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
