| Ref | Part Number | Description |
|---|
| 1 |
603-0719A-0637 |
HOOD HINGE ASSEMBLY Not Available Price: |
| 1 |
63-6410-03 |
TUBE-PUMP, CONTROL ASM This part replaces 63-6410. Price: $187.48 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
625-0052 |
HEADLIGHT ASSEMBLY-F Not Available Price: |
| 3 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 3 |
703-05281-0637 |
PANEL MOUNTING BRACKET (RH) (POWDER BLACK) Not Available Price: |
| 4 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 4 |
703-05284-0637 |
PANEL MOUNTING BRACKET (RH) (POWDER BLACK) Not Available Price: |
| 5 |
27-3680 |
SPACER-MOUNTING Price: $6.65 |
| 5 |
703-05293-0637 |
PANEL MOUNTING BRACKET (LH) (POWDER BLACK) Not Available Price: |
| 6 |
703-05295-0637 |
PANEL MOUNTING BRACKET (LH) (POWDER BLACK) Not Available Price: |
| 6 |
99-5677 |
TRANSMISSION ASM This part replaces 92-5513. Price: $4,071.30 |
| 7 |
237-42 |
O-RING Price: $2.78 |
| 7 |
703-3394-0637 |
INTAKE SCREEN Not Available This part replaces 703-3394. Price: |
| 8 |
353-979 |
FITTING-STR Price: $12.62 |
| 8 |
703-3712A |
SHIELD, UPPER HEAT Not Available Price: |
| 9 |
66-3110 |
FITTING-HYD, 90 DEG Price: $61.37 |
| 9 |
703-3764-0637 |
Bracket, Panel Mtg. Price: Call Us |
| 10 |
27-4370 |
HUB-PUMP Price: $70.04 |
| 10 |
703-3765-0637 |
Shield, Lower Heat Price: Call Us |
| 11 |
710-0473 |
Screw, Truss Hd, 10-24 x .5 Price: $3.90 |
| 12 |
3210-5 |
SCREW-HH Price: $0.54 |
| 12 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 13 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 13 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 14 |
32152-5 |
NUT-HEX Price: $0.54 |
| 14 |
710-3170 |
SCREW 5/16-18 x .56 Not Available Price: |
| 15 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 15 |
712-0272 |
Nut, Hex Sems, 10-24 Price: $3.58 |
| 16 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 16 |
712-0324 |
Nut, Hex Nylon Insert Lock, 1/4-20 Price: $3.38 |
| 17 |
63-6610-03 |
DRIVE SHAFT ASM This part replaces 63-6610. Price: $79.41 |
| 17 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 18 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 19 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 19 |
726-04010 |
RETAINER CLIP Not Available Price: |
| 20 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 20 |
726-3056 |
Latch, 1/4 Turn Panel Price: $6.20 |
| 21 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 21 |
727-3194 |
Cylinder, Gas Spring Price: $106.14 |
| 22 |
27-6590 |
SPACER-COUPLING, RUBBER Price: $13.38 |
| 22 |
931-04540 |
SIDE PANEL (LH) Not Available This part replaces 731-04540. Price: |
| 23 |
66-8490 |
HOSE-HYD Price: $140.41 |
| 23 |
931-04541 |
SIDE PANEL (RH) Not Available This part replaces 731-04541. Price: |
| 24 |
3210-8 |
SCREW-HH Price: $1.02 |
| 25 |
237-22 |
O-RING Price: $2.43 |
| 25 |
726P05561 |
PANEL LATCH This part replaces 732-0936. Price: $30.60 |
| 26 |
732-0937 |
Spring, Compression Price: $7.18 |
| 26 |
82-8530 |
FITTING-STR,ORIF Price: $36.90 |
| 27 |
23-2300 |
FILTER-OIL, TRANSMISSION Price: $11.03 |
| 27 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 28 |
323-39 |
SCREW-HH Price: $1.60 |
| 29 |
27-9620 |
SCREW-HH Price: $16.90 |
| 30 |
5-0652 |
SPACER Price: $5.35 |
| 31 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 32 |
92-5085 |
UNION-FILTER Price: $86.00 |
| 33 |
92-5087 |
SEAL-ADAPTOR, FILTER Price: $25.51 |
| 34 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 35 |
92-5082 |
HOSE-HYD Price: $25.51 |
| 36 |
86-7220 |
GEAR-PINION Price: $81.33 |
| 37 |
93-6125 |
Ring-Retaining Price: Call Us |
| 38 |
27-3690 |
GASKET-TRANSMISSION Price: $8.27 |
| 39 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 40 |
2412-4 |
CLAMP-R Price: $4.22 |
| 41 |
63-7170 |
ANCHOR-TRANSMISSION Price: $37.61 |
| 42 |
3218-3 |
NUT-JAM Price: $0.25 |
| 43 |
67-1900 |
SCREW-HH Price: $3.46 |
| 44 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 45 |
92-5076 |
ADAPTER-FILTER Price: $266.19 |
| 46 |
237-79 |
O-RING Price: $5.46 |
| 47 |
92-5086 |
FITTING-ELBOW, 90 DEG Price: $53.77 |
| 48 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 49 |
92-5083 |
HOSE-HYD Price: $25.27 |
| 50 |
3220-7 |
NUT-JAM Price: $4.09 |
| 51 |
237-78 |
O-RING Price: $3.85 |
| 52 |
237-78 |
O-RING Price: $3.85 |
| 52 |
92-5512 |
FITTING-STR Price: $21.46 |
| 55 |
353-988 |
PLUG-HEX Price: $10.61 |
| 56 |
353-990 |
PLUG ASM Price: $10.01 |
| 57 |
38-3400 |
GUARD-RUBBER Price: $8.02 |
