| Ref | Part Number | Description |
|---|
| 1 |
93-9322 |
PUMP-HYD This part replaces 69-3040. Price: $3,885.37 |
| 2 |
32128-21 |
NUT-HF Price: $0.39 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
71-0520 |
DISCONTINUED Price: Call Us |
| 4 |
71-0530 |
DISCONTINUED Price: Call Us |
| 5 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 6 |
71-0510 |
DISCONTINUED Price: $2.00 |
| 7 |
2115-88 |
DISCONTINUED - SEE PB#753 Price: Call Us |
| 8 |
71-0500 |
DISCONTINUED Price: Call Us |
| 9 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
33114-020 |
SCREW-HH This part replaces 48-7710. Price: $0.28 |
| 11 |
3274-50 |
SCREW-HSH Price: $0.88 |
| 12 |
325-7 |
SCREW-HH Price: $1.53 |
| 12 |
532405140 |
PULLEY.ENGINE.5.0.PD Price: $44.99 |
| 13 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 14 |
3217-9 |
NUT-HH Price: $0.37 |
| 15 |
237-81 |
O-RING Price: $2.76 |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 532414151. Price: $329.99 |
| 16 |
340-131 |
FITTING-HYD, 90 DEG Price: $99.83 |
| 17 |
237-30 |
O-RING Price: $2.50 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 This part replaces 532420635. Price: $37.99 |
| 18 |
69-5460 |
HOSE ASM Price: $86.10 |
| 19 |
237-146 |
O-RING Price: $3.75 |
| 20 |
340-15 |
FITTING-ELBOW 90 Price: $47.39 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
237-58 |
O-RING Price: $2.18 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
69-5650 |
HYD HOSE ASM Price: $137.75 |
| 23 |
237-42 |
O-RING Price: $2.78 |
| 24 |
72-3790 |
DISCONTINUED Price: Call Us |
| 26 |
69-9020 |
NUT-SPECIAL Price: $13.84 |
| 27 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
69-9480-03 |
BRACKET-DEVICE, NEUTRAL This part replaces 69-9480. Price: $62.58 |
| 29 |
3219-2 |
NUT-HEX Price: $0.37 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 31 |
69-9040-03 |
CAM-DEVICE, NEUTRAL This part replaces 69-9040. Price: $26.07 |
| 32 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 33 |
3231-30 |
SCREW-CARR Price: $4.27 |
| 34 |
3217-7 |
NUT-HEX Price: $0.28 |
| 35 |
29-6162 |
SWITCH-MICRO Price: $107.13 |
| 36 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 37 |
3296-9 |
NUT-HEX Price: $0.25 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 39 |
322-17 |
SCREW-HH Price: $2.62 |
| 40 |
3210-7 |
SCREW-HH Price: $0.61 |
| 41 |
251-259 |
BEARING-BALL Price: $13.67 |
| 42 |
321-4 |
SCREW-HH Price: $0.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 44 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 45 |
69-9050 |
BAR-DEVICE, NEUTRAL Price: $60.77 |
| 46 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 47 |
321-10 |
SCREW-HH Price: $1.29 |
| 48 |
340-134 |
FITTING-ELBOW, 90 Price: $8.43 |
| 49 |
41-8760 |
GASKET Price: $5.99 |
| 50 |
69-5663 |
DISCONTINUED Price: Call Us |
| 51 |
323-7 |
SCREW-HH Price: $0.65 |
| 52 |
69-2220 |
PUMP-GEAR Price: $2,044.00 |
| 53 |
237-80 |
O-RING This part replaces 327-80. Price: $6.10 |
| 54 |
340-130 |
FITTING-ELBOW 90 Price: $99.83 |
| 55 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 56 |
69-5450 |
HOSE ASM Price: $84.07 |
| 57 |
69-5470 |
HOSE ASSEMBLY Price: $247.74 |
| 58 |
69-5440 |
HOSE ASM Price: $73.25 |
| 59 |
69-5480 |
HOSE ASSEMBLY Price: $276.13 |
| 60 |
51-3150 |
SHIM-ARM, SPRING Price: $5.24 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
