| Ref | Part Number | Description |
|---|
| 1 |
137-6110 |
TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 115-8297-03. Price: $273.64 |
| 1 |
530094686 |
Clamp Harness Ass'y. Price: $4.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
530092192 |
Handlebar Cap Price: $0.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
530015197 |
Nut Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
530069347 |
HANDLE KIT This part replaces 530069252. Price: $4.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
530027778 |
Handlebar Warning Decal Price: $0.12 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
530015791 |
Screw Price: $1.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
530091783 |
Retainer Price: $1.99 |
| 8 |
530069086 |
Bearing & Spacer Kit Price: $22.99 |
| 9 |
530092216 |
Washer Price: $1.99 |
| 10 |
530094572 |
Handlebar Bracket Price: $1.99 |
| 11 |
530092086 |
Handlebar Grip Price: $4.99 |
| 12 |
530092359 |
Dust Cup Price: $4.99 |
| 13 |
530010723 |
Handlebar Price: $6.68 |
| 14 |
530094571 |
Grass Washer Price: $1.99 |
| 15 |
530094585 |
Drive Shaft Model HP30SB Price: $19.99 |
| 15 |
530095146 |
Drive Shaft Model HP28 Price: $9.99 |
| 16 |
530029162 |
Shaft Warning Decal-Upper Price: $3.33 |
| 17 |
530029163 |
Shaft Warning Decal-Lower Price: $3.33 |
| 18 |
530012207 |
Handlebar Clamp Price: $8.99 |
| 19 |
530014772 |
Drive Shaft Housing Model HP28 Price: $27.99 |
| 19 |
530094684 |
Drive Shaft Housing Model HP30SB Price: $35.03 |
| 21 |
530027749 |
Blade Direction Decal Price: $0.12 |
| 22 |
530016107 |
Screw This part replaces 530092243. Price: $1.99 |
| 23 |
530015328 |
Lockwasher Price: $1.99 |
| 24 |
530094612 |
Screw Price: $0.99 |
| 25 |
530001711 |
Screw Price: $1.99 |
| 26 |
530001642 |
Lockwasher Price: $1.99 |
| 27 |
530031159 |
Hex Wrench (5/32) This part replaces 530031111. Price: $1.99 |
| 28 |
530071781 |
GEAR BOX REPLACEMENT KIT This part replaces 530094568. Price: $74.99 |
| 29 |
530094616 |
Screw Price: Call Us |
| 30 |
530094633 |
SHIELD This part replaces 530094627. Price: $22.99 |
| 31 |
530027615 |
Shield Retention Plate Price: $3.99 |
| 33 |
530015792 |
Washer Price: $1.99 |
| 34 |
530016240 |
Washer--Belleville This part replaces 530015492. Price: $1.99 |
| 35 |
530015793 |
Nut Price: $1.99 |
| 36 |
530031098 |
Hex Wrench (3/16) Price: $0.99 |
| 37 |
530094417 |
Shoulder Strap Price: $20.65 |
| 38 |
952701611 |
Weed Blade Price: $26.19 |
| 39 |
530094640 |
Seal Price: $6.94 |
| 40 |
530015037 |
Screw Price: $1.99 |
| 41 |
530094570 |
Line Limiter Price: $1.99 |
| 42 |
530001543 |
Nut Price: Call Us |
| 45 |
530071295 |
Hub This part replaces 530093896. Price: $14.99 |
| 46 |
530093898 |
Line Saver Price: $3.99 |
| 47 |
530340007 |
Spring Price: $1.99 |
| 48 |
530328929 |
Cap Spring This part replaces 530092068. Price: $1.99 |
| 49 |
530093897 |
Drive Gear Price: $6.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 50 |
952701589 |
Spool w/ Line Price: $5.95 |
| 51 |
530401183 |
Tap Button This part replaces 530093387. Price: $2.99 |
| 52 |
530092133 |
Cover Price: $5.99 |
| 54 |
530014773 |
Hub Ass'y. Price: $8.99 |
| 55 |
530094830 |
Spring Price: $1.99 |
| 56 |
530094827 |
Release Button Price: $3.99 |
| 57 |
952701619 |
Spool w/Line Price: $5.95 |
| 58 |
530094828 |
Cover Price: $8.99 |
| 60 |
530015610 |
Nut Price: $0.99 |
| 61 |
530094742 |
Clamp Price: $2.99 |
