| Ref | Part Number | Description |
|---|
| 1 |
728-0175 |
Pop Rivet Price: $4.04 |
| 2 |
753-05094 |
Chipper Shredder Chute Price: $128.73 |
| 3 |
735-0249A |
Chute Flap Price: $21.78 |
| 4 |
781-0633 |
Chute Flap Strip Price: $9.09 |
| 5 |
681-04119A-4044 |
LOWER CHIPPER CHUTE (CRAFTSMAN RED) This part replaces 681-04119-4044. Price: $105.28 |
| 6 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 7 |
712-04064 |
Hex Lock Nut 1/4-20 Price: $3.64 |
| 8 |
710-0809 |
Hex Cap Screw 1/4-20 x 1.25 Price: $6.37 |
| 9 |
736-0173 |
Flat Washer .28 ID x .74 OD Price: $3.76 |
| 10 |
736-0242 |
Bell Washer .340 ID x .872 OD Price: $3.75 |
| 11 |
712-3010 |
HEX NUT 5/16-18 This part replaces 912-3010. Price: $3.89 |
| 12 |
749-1004-4044 |
Support Brace Price: $38.35 |
| 13 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 14 |
710-3180 |
Hex Cap Screw 5/16-18 x 1.75 Price: $4.93 |
| 15 |
736-0170 |
SPECIAL WASHER Not Available This part replaces 936-0170. Price: |
| 16 |
950-0786 |
Spacer Price: $6.28 |
| 17 |
738-0813 |
Axle Assembly Price: $46.13 |
| 18 |
737-0298 |
PIPE DRAIN 1/4 NPT Not Available Price: |
| 19 |
934-04009 |
Wheel Complete, 10.0 x 4.0 Gray Not Available Price: |
| 20 |
726-0214 |
Push Cap Price: $9.11 |
| 21 |
681-0183B-4044 |
FRAME ASSEMBLY (CRAFTSMAN RED) Not Available Price: |
| 22 |
736-0451 |
Saddle Wash. .32" I.D. This part replaces 936-0451. Price: $3.75 |
| 23 |
710-0502A |
Screw, 3/8-16 x 1.250 Price: $5.71 |
| 26 |
737-0132 |
Oil Drain End Cap Price: $9.61 |
| 27 |
731-1617 |
Tamper Price: $122.92 |
