| Ref | Part Number | Description |
|---|
| 1 |
304-46 |
DRAINCOCK Price: $7.55 |
| 2 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 5 |
117-5135 |
RADIATOR Price: $1,486.25 |
| 6 |
100-4885-03 |
SHROUD-FAN, TOP Price: $178.08 |
| 7 |
119-2008-03 |
SHROUD-FAN, LOWER This part replaces 110-8798-03. Price: $147.80 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 9 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 10 |
104-4855-03 |
FRAME-RADIATOR Price: $371.50 |
| 11 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 14 |
100-4899-03 |
BRACKET-RESERVOIR Price: $85.27 |
| 20 |
95-8702-0P |
SHIELD-RADIATOR, LOWER This part replaces 95-8702-03. Price: $47.95 |
| 21 |
99-3497 |
MAGNET Price: $20.22 |
| 22 |
100-4869 |
COOLER-OIL Price: $791.17 |
| 23 |
104-0454 |
HOSE-RADIATOR, UPPER Price: $87.07 |
| 24 |
100-4809 |
HOSE-RADIATOR, LOWER Price: $70.44 |
| 25 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 26 |
99-3644 |
TUBE-HEAD, FILTER Price: $76.72 |
| 27 |
100-4925 |
FITTING-BULKHEAD Price: $182.03 |
| 28 |
99-3646 |
HOSE-COOLER, OIL Price: $34.95 |
| 33 |
99-7435 |
RELAY Price: $32.43 |
| 34 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 35 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 37 |
115-3489 |
TUBE ASM Price: $187.52 |
| 38 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 41 |
93-6681 |
DECAL-WARNING, FAN Price: $11.51 |
| 42 |
32128-20 |
NUT-HF Price: $0.99 |
| 43 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 44 |
100-4866 |
GROMMET Price: $13.73 |
| 45 |
100-4858 |
FORM-WIRE Price: $3.05 |
| 46 |
100-4859 |
BRACKET-COOLER, KEEPER Price: $63.02 |
| 47 |
100-4860 |
BRACKET-CLAMP Price: $25.40 |
| 48 |
322-17 |
SCREW-HH Price: $2.62 |
| 49 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
