| Ref | Part Number | Description |
|---|
| 1 |
68-5460 |
BATTERY CABLE Price: $103.33 |
| 2 |
106-5190 |
BATTERY This part replaces 63-9230. Price: $170.85 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
68-5500 |
BATTERY CABLE (NEG) Price: $65.93 |
| 4 |
76-4380 |
FUEL TANK Price: $549.75 |
| 5 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 6 |
321-4 |
SCREW-HH Price: $0.99 |
| 7 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 8 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 9 |
55-3577 |
DISCONTINUED Price: Call Us |
| 12 |
237-136 |
GROMMET Price: $3.52 |
| 13 |
323-6 |
SCREW-HH Price: $0.66 |
| 14 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
68-5510 |
DISCONTINUED Price: Call Us |
| 16 |
56-2520 |
FITTING-SHUT OFF, FUEL Price: $31.19 |
| 17 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 19 |
53-8150 |
PUMP-FUEL Price: $680.19 |
| 20 |
67-1690 |
FITTING-SPECIAL Price: $8.57 |
| 21 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 22 |
2412-89 |
CLAMP-R Price: $2.09 |
| 23 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 24 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 26 |
353-707 |
FITTING-HYD, 90 DEG Price: $43.04 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
63-7650 |
SEPARATOR-FILTER / WATER This part replaces 63-8280. Price: $155.85 |
| 30 |
63-8290 |
VENT-AIR Price: $19.94 |
| 31 |
63-8300 |
ELEMENT-SPIN ON Price: $28.79 |
| 32 |
63-8310 |
VALVE-DRAIN Price: $13.54 |
| 33 |
52-1890 |
RUBBER WELLNUT Price: $19.90 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
237-124 |
GROMMET Price: $2.30 |
| 35 |
37-2690 |
CAPACITOR Price: $155.98 |
| 35 |
583864502 |
Rods This part replaces 532435486. Price: $6.99 |
| 36 |
2412-74 |
R-CLAMP Price: $2.37 |
| 37 |
51-0350 |
PIN-SPRING, SEAT Price: $11.90 |
| 38 |
3-6685 |
SPRING Price: $10.99 |
| 39 |
3284-3 |
PIN-GROOVED Price: $2.24 |
| 40 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 41 |
237-30 |
O-RING Price: $2.50 |
| 42 |
43-8610 |
GUIDE Price: $23.35 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 44 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 45 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 46 |
237-7 |
O-RING Price: $8.82 |
| 47 |
218-461 |
NUT-HH Price: $2.50 |
| 48 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 49 |
109-0309 |
HOSE-FUEL This part replaces 63-7623. Price: $18.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
353-783 |
FITTING-STR Price: $29.05 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
53-9880 |
WASHER Price: $10.84 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
52-1880 |
DISCONTINUED Price: Call Us |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
66-8800 |
RELAY Price: $87.56 |
| 54 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 55 |
63-7590 |
RELAY Price: $78.15 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 57 |
68-5680 |
DISCONTINUED Price: Call Us |
| 59 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 60 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 61 |
323-9 |
SCREW-HH Price: $1.29 |
| 62 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 63 |
70-8510 |
DISCONTINUED Price: Call Us |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 65 |
70-8530 |
DISCONTINUED Price: Call Us |
| 66 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 67 |
76-4420 |
HOSE-LINE, FUEL Price: $6.91 |
| 68 |
76-4430 |
FITTING - FUEL 90 DEG Price: $73.61 |
| 69 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 80 |
531064101 |
SERVICE KIT TORQUE STRAP BLACK This part replaces 532440619. Price: $19.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532441455. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532195804 |
LINK.CLUTCH.ANIT-ROTAT Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 226 |
531170501 |
SERVICE KIT BRACKET This part replaces 532401564. Price: $4.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
