| Ref | Part Number | Description |
|---|
| 2 |
42-8000 |
INJ PUMP Price: $2,367.11 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
42-9830 |
DISCONTINUED Price: Call Us |
| 4 |
42-8100 |
COLLAR MM 304916 Price: $28.56 |
| 7 |
531170101 |
SERVICE.KIT HUB ASM HUB.ASM.WH This part replaces 532199844. Price: $49.99 |
| 8 |
56-0750 |
CLAMP This part replaces 42-8160. Price: $15.09 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
33113-025 |
SCREW-HH This part replaces 43-2600. Price: $1.97 |
| 11 |
42-8140 |
PIPE ASY. Price: $95.38 |
| 13 |
56-0760 |
CLAMP This part replaces 42-8170. Price: $7.97 |
| 14 |
33114-020 |
SCREW-HH This part replaces 43-0110. Price: $0.28 |
| 15 |
42-8010 |
ADJ SHIM MM 409040 Price: $13.75 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
281-1 |
PLUG-PIPE, SQH Price: $4.56 |
| 17 |
42-7090 |
SEALING CAP Price: $27.82 |
| 17 |
532401072 |
SPRING.BRAKE.K46 Price: $6.99 |
| 18 |
42-7050 |
OIL GA GUIDE Price: $21.44 |
| 19 |
43-2710 |
O-RING Price: $6.47 |
| 20 |
72-6950 |
OIL LEVEL GUAGE RETAIN. This part replaces 43-2900. Price: $33.80 |
| 21 |
42-7160 |
PIN Price: $4.51 |
| 22 |
42-7270 |
OIL GAUGE Price: $39.93 |
| 23 |
42-9660 |
WASHER Price: $2.50 |
| 25 |
42-7410 |
DISCONTINUED Price: Call Us |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 31 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 32 |
33114-016 |
SCREW-HH This part replaces 42-9230. Price: $0.27 |
| 33 |
42-8180 |
FUEL RETURN ASM Price: $39.29 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
2412-79 |
CLAMP-HOSE Price: $1.63 |
| 35 |
42-8190 |
JOINT MM 100088 Price: $13.50 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 36 |
67-2390 |
PLUG This part replaces 42-7210. Price: $5.06 |
| 37 |
42-7290 |
GASKET-PLUG This part replaces 42-8880. Price: $7.56 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
67-2520 |
PLUG This part replaces 42-8870. Price: $5.65 |
| 39 |
42-8930 |
SPRING MM 407142 Price: $16.42 |
| 40 |
67-2500 |
PLUNGER This part replaces 42-8860. Price: $22.88 |
| 41 |
92-1978 |
OIL PRESSURE SWITCH This part replaces 42-9060. Price: $63.87 |
| 42 |
42-9030 |
FILTER-OIL Price: $10.31 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
42-9480 |
DISCONTINUED Price: Call Us |
| 44 |
42-8920 |
DISCONTINUED Price: Call Us |
| 45 |
42-8910 |
PUMP ROTOR Price: $416.87 |
| 46 |
42-8940 |
O-RING Price: $28.65 |
| 47 |
42-7030 |
DISCONTINUED Price: Call Us |
| 48 |
42-8900 |
PUMP BODY MM 409201 Price: $249.04 |
| 49 |
42-8950 |
BODY GASKET MM 407124 Price: $13.24 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
42-7180 |
DISCONTINUED Price: Call Us |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
42-7170 |
PLUG-40 MM MF665511 Price: $11.46 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
42-7200 |
KNOCK BSHG MS 471110 Price: $10.16 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
93-3409 |
BEARING This part replaces 42-7820. Price: $33.38 |
| 54 |
42-7840 |
SUNK KEY Price: $9.67 |
| 55 |
42-7810 |
DISCONTINUED Price: Call Us |
| 56 |
42-7790 |
IDLER GEAR Price: $383.30 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 57 |
42-7780 |
DISCONTINUED Price: Call Us |
| 58 |
42-7730 |
DISCONTINUED Price: Call Us |
| 59 |
72-4280 |
CAM SHAFT Price: $839.96 |
| 62 |
48-7880 |
NUT-HEX This part replaces 43-5970. Price: $0.25 |
| 63 |
43-5920 |
WASHER-LOCK, SPRING Price: $0.25 |
| 64 |
33014-00 |
NUT-HEX This part replaces 42-9580. Price: $0.25 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 65 |
43-0370 |
DISCONTINUED Price: Call Us |
| 66 |
43-0380 |
DISCONTINUED Price: Call Us |
| 67 |
112-1359 |
ALTERNATOR This part replaces 43-0390. Price: $469.33 |
| 68 |
43-1900 |
BOLT MD 017625 Price: $17.40 |
| 69 |
54-8660 |
WASHER Price: $2.23 |
| 70 |
532439661 |
CONSOLE.ASM.RH.GT.FC.HUSQ This part replaces 532400530. Price: $79.99 |
| 70 |
67-4660 |
BOLT-FLANGE This part replaces 54-8650. Price: $2.64 |
| 71 |
43-0400 |
GEN BRACE MM 409463 Price: $68.06 |
| 72 |
42-7190 |
DISCONTINUED Price: Call Us |
| 73 |
42-9820 |
DISCONTINUED Price: Call Us |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 80 |
532404483 |
STRAP.TORQUE.HG3000/K46 Price: $17.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT This part replaces 532195403. Price: $9.99 |
| 162 |
580457401 |
SPACER.TRANSAXLE.1" This part replaces 532195785. Price: $12.99 |
| 163 |
593861001 |
Rods This part replaces 532401034. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 This part replaces 532197290. Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532196211. Price: $2.99 |
| 169 |
583613301 |
BOLT.HEX.FLNG.5/16-18X3.75 This part replaces 874490560. Price: $4.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
596435101 |
Bolts This part replaces 872110620. Price: $2.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532195804 |
LINK.CLUTCH.ANIT-ROTAT Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX This part replaces 532401722. Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 218 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 219 |
532195780 |
SPACER.FENDER Price: $5.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
734118571 |
WASHER This part replaces 819212010. Price: $1.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
