Lift Assembly
Parts (66)
| Ref | Part Number | Description |
|---|---|---|
| 201 | 805480 | Link Price: Call Us |
| 209 | 805463 | Governor Spring Price: Call Us |
| 209A | 805450 | Spring-Governor Price: Call Us |
| 209B | 805453 | Spring-Governor Price: Call Us |
| 216 | 805439 | Link Price: Call Us |
| 222 | 808195 | Bracket-Control Price: Call Us |
| 227 | 807528 | Lever-Governor Price: Call Us |
| 232 | 805465 | Spring-Link Price: Call Us |
| 265 | 221535 | Clamp-Casing Price: Call Us |
| 271 | 808145 | Lever-Control Price: Call Us |
| 277 | 805018 | Washer Price: Call Us |
| 307 | 805025 | Screw Price: Call Us |
| 351 | 805169 | Screw-Hex. Price: Call Us |
| 562 | 805381 | Bolt Price: Call Us |
| 506510801 | 506510801 | CLEVIS PIN Price: $9.99 |
| 506522401 | 506522401 | ROLLER Price: $9.99 |
| 506556501 | 584871301 | BEARING FLANGE This part replaces 506556501. Price: $4.99 |
| 506756801 | 506756801 | LEVER Price: $159.99 |
| 506757101 | 506757101 | NUT Price: $44.99 |
| 506759502 | 506759502 | Price: $15.61 |
| 506768801 | 506768801 | Bushing Price: $4.47 |
| 506784201 | 506784201 | PIN Price: $19.29 |
| 506784301 | 506784301 | LEVER CLUTCH Price: $29.99 |
| 506831201 | 506831201 | Price: $47.37 |
| 506831501 | 506831501 | Price: $6.95 |
| 506831601 | 506831601 | KNOB Price: $4.05 |
| 506831701 | 506831701 | END PIECE Price: $11.99 |
| 506831801 | 506831801 | CATCH Price: $19.99 |
| 506831901 | 506831901 | Price: $38.25 |
| 506832201 | 506832201 | Price: $7.60 |
| 506832301 | 506832301 | SPRING Price: $3.99 |
| 506833901 | 506833901 | Price: $74.68 |
| 506834301 | 506834301 | SPRING Price: $3.99 |
| 506834701 | 506834701 | Price: $7.45 |
| 506834801 | 506834801 | Price: $3.86 |
| 506834901 | 506834901 | Price: $6.76 |
| 506835001 | 506835001 | Price: $5.66 |
| 506835201 | 506835201 | Price: $14.76 |
| 506835601 | 506835601 | Index Plate Price: $35.20 |
| 506835701 | 506835701 | Clamp Price: $20.70 |
| 506870501 | 506870501 | Price: $38.25 |
| 506870701 | 506870701 | Price: $15.17 |
| 506894001 | 506894001 | Price: Call Us |
| 506900401 | 506900401 | Price: $6.80 |
| 506900501 | 506900501 | Price: $37.46 |
| 506900801 | 506900801 | Price: $37.75 |
| 506901101 | 506901101 | LOOP Price: $17.99 |
| 721421226 | 721421226 | SPRING PIN 3X24 Price: $4.99 |
| 721425070 | 721425070 | Price: $0.79 |
| 721618301 | 721618301 | Split Pin Price: $1.99 |
| 721618701 | 721618701 | COTTER PIN Price: $3.99 |
| 725233551 | 725233551 | SCREW Price: $3.99 |
| 725237471 | 725237471 | SCREW M6S 6X30 Price: $4.99 |
| 725245351 | 725245371 | SCREW This part replaces 725245351. Price: $4.99 |
| 725245751 | 725245751 | SCREW Price: $4.99 |
| 725246051 | 725246351 | SCREW This part replaces 725246051. Price: $4.99 |
| 725249751 | 725249751 | SCREW Price: $4.99 |
| 729440801 | 729440801 | Screw Price: $1.32 |
| 731231201 | 731231201 | NUT M6M M4 Price: $3.99 |
| 731231801 | 731231801 | NUT Price: $3.99 |
| 731232051 | 731232001 | Nut This part replaces 731232051. Price: $3.99 |
| 732211401 | 732211401 | LOCKNUT M5 Price: $2.99 |
| 732211601 | 732211601 | LOCKNUT M6 Price: $4.99 |
| 732211801 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 732251201 | 588222101 | HEXAGON NUT FLANGE M4 A2-70 This part replaces 732251201. Price: $2.99 |
| 735311420 | 735311420 | RETAINING RING Price: $2.99 |
